NC7S32M5X_F080

Inverter Gates Overview

The NC7S32M5X_F080 is a single two-input OR gate from onsemi’s TinyLogic UHS series. It utilizes advanced CMOS technology to deliver ultra-high speed performance with high output drive capability while maintaining low static power dissipation across a broad VCC operating range of 1.65 V to 5.5 V. The device features inputs and outputs that remain high impedance when VCC is 0 V, and its inputs tolerate voltages up to 5.5 V independent of the VCC operating voltage.

Inverter Gates Feature Summary

• Ultra-High Speed operation with typical propagation delay of 2.4 ns into 50 pF at 5 V VCC
• High Output Drive capability providing ±24 mA at 3 V VCC
• Broad VCC Operating Range supporting 1.65 V to 5.5 V
• Over-Voltage Tolerance Inputs facilitating 5 V to 3 V translation

Inverter Gates Applications

• General purpose logic applications requiring high speed
• Portable equipment due to low power consumption
• Battery-powered systems utilizing wide voltage ranges
• Signal processing circuits requiring fast switching

Inverter Gates Procurement Notes

Verify the specific suffix F080 against official datasheets to confirm tape-and-reel packaging specifications and quantity per reel. Ensure compatibility with existing PCB footprint SC-74A or SC-88A packages. Confirm RoHS compliance and halogen-free status for environmental regulations. Cross-reference pinout configurations to prevent integration errors during assembly.

Inverter Gates Selection Notes

Select this component for designs needing fast switching speeds in compact spaces. It suits applications where power efficiency is critical alongside signal integrity. Consider the wide input voltage tolerance if interfacing between different logic families. Evaluate the package size constraints against available board space for optimal layout.

Inverter Gates Part Context

This part belongs to onsemi’s TinyLogic family, known for small footprints and high performance. The UHS series specifically targets ultra-high speed requirements within the standard logic gate category. It serves as a direct replacement for legacy components in modern miniaturized electronic designs.

Inverter Gates Replacement Considerations

Check for functional equivalents within the same TinyLogic UHS series. Verify pin-to-pin compatibility with alternative manufacturers' OR gates. Ensure electrical characteristics match the original design requirements before substitution.
