NCS2004AMUTAG

Instrumentation, Op Amps, Buffer Amps Overview

The NCS2004AMUTAG is a general-purpose operational amplifier from onsemi, featuring rail-to-rail output operation. It provides high slew rate performance with low offset voltage and low input bias current of 45pA. The device operates within a supply voltage range of 2.7V to 12V and delivers an output current of 13mA per channel. Key electrical characteristics include a gain-bandwidth product of 3.5MHz and a supply current of 400µA. It is housed in a compact 6-UDFN (1.6x1.6) package.

Instrumentation, Op Amps, Buffer Amps Feature Summary

• Rail-to-rail output capability for maximum dynamic range
• High slew rate for fast signal response
• Low input bias current of 45pA for minimal loading
• Compact 6-UDFN package design

Instrumentation, Op Amps, Buffer Amps Applications

• General-purpose analog signal conditioning
• Battery-powered portable devices
• Sensor interface circuits
• Audio pre-amplification stages

Instrumentation, Op Amps, Buffer Amps Procurement Notes

Verify the specific suffix 'A' against the manufacturer's official documentation to confirm pinout and electrical specifications, as suffixes often denote tape-and-reel packaging or specific temperature grades. Ensure the selected component matches the required operating temperature range and package dimensions for your PCB layout. Cross-reference the ordering part number with the latest datasheet revision to avoid discrepancies in mechanical drawings or electrical limits.

Instrumentation, Op Amps, Buffer Amps Selection Notes

Select this component when rail-to-rail output swing is critical for single-supply applications. The low input bias current makes it suitable for high-impedance sensor interfaces. Compare its 3.5MHz gain-bandwidth product against application requirements to ensure sufficient bandwidth. Consider the 6-UDFN package size if space constraints are a primary design factor compared to larger packages.

Instrumentation, Op Amps, Buffer Amps Part Context

The NCS2004 series belongs to onsemi's portfolio of precision operational amplifiers designed for cost-sensitive and space-constrained applications. This specific model represents a general-purpose variant optimized for balanced performance between speed and power consumption. It is part of a broader family that includes similar amplifiers with varying bandwidth and noise characteristics, catering to diverse industrial and consumer electronics needs.

Instrumentation, Op Amps, Buffer Amps Replacement Considerations

Check for direct pin-compatible replacements within the NCS2004 family or other rail-to-rail op-amps with similar 3.5MHz GBW and 45pA bias current. Verify that alternative components meet the 2.7V minimum supply voltage requirement and offer comparable output drive capabilities.
