NDS36PT5-16IT

Memory IC Overview

The NDS36PT5-16IT is a SDRAM memory IC manufactured by Insignis Technology Corporation. It features a storage capacity of 256Mb organized as 16M x 16. The device operates with an LVTTL interface and supports a clock frequency of 166 MHz. It requires a supply voltage between 3V and 3.6V. The component is housed in a 54-TSOP II package, measuring 0.400 inches (10.16mm) in width. It functions within a temperature range of -40°C to 85°C.

Memory IC Feature Summary

• Provides 256Mb volatile DRAM storage using SDRAM technology.
• Supports high-speed data transfer via LVTTL interface at 166 MHz.
• Designed for surface mount installation in compact electronic systems.

Memory IC Applications

• Embedded memory systems requiring parallel data access
• Industrial control units operating in extended temperature ranges
• Consumer electronics utilizing low-voltage logic interfaces

Memory IC Procurement Notes

Verify the specific suffix 'TR' when ordering, as it indicates tape and reel packaging. Confirm that the 54-TSOP II footprint matches the target PCB design. Ensure power supply rails remain stable within the 3V to 3.6V specification during operation. Check RoHS3 compliance status if environmental regulations apply to the final assembly.

Memory IC Selection Notes

Select this component when a 256Mb density is required with LVTTL compatibility. The 166 MHz speed suits applications not demanding higher frequencies like the 200 MHz variant. The TSOP II package offers a balance between pin count and board space. Consider the -40°C to 85°C rating for industrial or automotive environments.

Memory IC Part Context

This part belongs to the NDS36P series of synchronous dynamic random-access memories. It shares the same core architecture and organization as other variants in the family but differs in speed grade and packaging. The NDS36PT5-16IT specifically targets designs needing reliable mid-range performance with standard logic levels.

Memory IC Replacement Considerations

NDS36PT5-20IT TR serves as a parameter-equivalent substitute offering higher speed capabilities.
