NDS63PT9-16ET

Memory IC Overview

The NDS63PT9-16ET is a Synchronous Dynamic Random Access Memory (SDRAM) integrated circuit manufactured by Insignis Technology Corporation. It provides a storage capacity of 256 Megabits, organized as 16 Megawords by 16 bits. The device supports parallel interface operation with a maximum clock frequency of 166 MHz. It is housed in a 54-pin TSOP II package and operates within a supply voltage range of 3V to 3.6V.

Memory IC Feature Summary

• Supports high-speed parallel data transfer via LVTTL interface
• Provides dense memory organization for system buffering
• Designed for surface-mount assembly in compact electronic devices

Memory IC Applications

• Portable consumer electronics requiring volatile memory
• Embedded systems utilizing parallel bus architectures
• Industrial control units needing fast data access

Memory IC Procurement Notes

Verify the specific suffix ET against official manufacturer documentation to confirm pinout compatibility and electrical characteristics. Ensure the source component matches the exact part number to avoid functional mismatches in parallel memory interfaces.

Memory IC Selection Notes

Select this component when a 256Mb SDRAM with a 16-bit width is required for designs supporting up to 166 MHz operation. Confirm that the target application utilizes a 3V to 3.6V power supply and accommodates the physical dimensions of the 54-TSOP II package.

Memory IC Part Context

This part belongs to the NDS63 series of synchronous DRAMs from Insignis Technology Corporation. These components are designed to replace older asynchronous memory solutions in applications demanding higher bandwidth and lower latency for data processing tasks.

Memory IC Replacement Considerations

Consult official substitution guides for compatible parts such as the NDS63PT9-16IT or similar variants within the same family, ensuring identical pin configurations and timing parameters.
