NFZ32SW901HN10L

Overview

The Murata NFZ32SW901HN10L is a surface-mount ferrite bead designed for high-frequency noise suppression. It features an impedance of 900 Ohms at 100 MHz and supports a maximum DC current of 2.05 A. The component has a maximum DC resistance of 54 mOhms and operates within a temperature range of -40°C to +85°C. It utilizes a 1210 (3225 metric) package with dimensions of 3.2 mm length, 2.5 mm width, and 1.55 mm height.

Feature Summary

• Provides targeted high-frequency noise suppression in advanced electronic systems
• Engineered for integration into power supplies and battery chargers
• Supports operation in portable devices and energy-efficient applications

Applications

• Power supply circuits
• Battery charger designs
• Portable electronic devices
• Energy-efficient system architectures

Procurement Notes

Verify the specific suffix HN10L against official Murata documentation to confirm exact impedance tolerance and packaging configuration. Ensure compatibility with standard SMD reflow profiles and check for RoHS compliance status in the latest datasheet before finalizing procurement specifications.

Selection Notes

Select this component when high impedance at 100 MHz is required alongside moderate current handling capabilities. The 1210 footprint offers a balance between thermal performance and board space efficiency. Confirm that the 54 mOhm DC resistance meets the voltage drop requirements of the target circuit design.

Part Context

This part belongs to the Murata EMIFIL NFZ series of ferrite beads. These components are widely used for EMI suppression in digital and analog circuits. The NFZ series is known for providing stable impedance characteristics across a broad frequency range, making it suitable for various consumer and industrial electronics.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material. Consult official Murata resources or distributor cross-reference tools for verified alternatives.
