NID30S24-15

NID30S24-15 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists MEAN WELL USA Inc.. Its product description is DC DC CONVERTER 15V 30W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for NID30S24-15

• Description：DC DC CONVERTER 15V 30W
• Series：NID30 (30W)
• Mfr：MEAN WELL USA Inc.
• Package：Box
• Type：Non-Isolated PoL Module
• Number of Outputs：1
• Voltage - Input (Min)：20V
• Voltage - Input (Max)：53V
• Voltage - Output 1：15V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：2A
• Power (Watts)：30 W
• Voltage - Isolation：-
• Applications：ITE (Commercial)
• Features：Remote On/Off, OCP, OVP, SCP
• Operating Temperature：-25°C ~ 65°C (With Derating)
• Efficiency：96%
• Mounting Type：Through Hole
• Package / Case：11-SIP Module
• Size / Dimension：2.00" L x 0.42" W x 0.51" H (50.8mm x 10.7mm x 13.0mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for NID30S24-15
