NJ-10M-6800

Oscillators Overview

The Taitien NJ-10M-6800 is a high-performance Oven-Controlled Crystal Oscillator (OCXO) operating at a nominal frequency of 10.0000 MHz. It utilizes a crystal resonator and delivers an output signal in Sine Wave format. The device requires a supply voltage of 12V and draws a maximum current of 400mA. It features exceptional frequency stability of ±30ppb and operates within a temperature range of -40°C to 85°C. The component is housed in a 6-SMD, No Lead package with 5 leads, measuring 1.430 inches in length, 1.070 inches in width, and 0.583 inches in height.

Oscillators Feature Summary

• Ultra-low phase noise performance for precise timing applications
• High frequency stability of ±30ppb across the operating temperature range
• Robust construction with low G-sensitivity characteristics

Oscillators Applications

• Telecommunications infrastructure requiring precise clock synchronization
• Test and measurement equipment demanding stable reference frequencies
• Navigation and satellite systems utilizing accurate timekeeping
• Industrial automation control systems

Oscillators Procurement Notes

Verify the specific output configuration and pinout compatibility before integration. Confirm that the 12V power supply meets the maximum current requirements of 400mA. Ensure the PCB layout accommodates the 6-SMD no-lead package dimensions. Check for RoHS compliance status if environmental regulations apply to your assembly process.

Oscillators Selection Notes

Select this model when superior phase noise and tight frequency stability are critical. Compare against XO or TCXO alternatives if lower power consumption is required, noting the OCXO's higher thermal management needs. Consider the SMD form factor for automated assembly processes. Validate the sine wave output interface against downstream circuit input specifications.

Oscillators Part Context

This oscillator belongs to the NJ-10M-6800 series from Taitien, designed for ultra-low phase noise applications. The series represents a category of high-performance OCXOs engineered for demanding environments. Taitien specializes in quartz crystals and oscillators, providing solutions for communication and navigation sectors. This specific part number denotes a standard 10MHz sine wave variant within their low-noise portfolio.

Oscillators Replacement Considerations

Direct substitutes may include other 10MHz OCXOs with similar ±30ppb stability and 12V operation. Verify pin-to-pin compatibility for the 6-SMD no-lead package. Cross-reference electrical parameters such as phase noise specs and startup time. Consult manufacturer documentation for approved alternate part numbers within the same series.
