NLFV25T-3R3M-EF

Fixed Inductors Overview

The NLFV25T-3R3M-EF is a shielded drum core, wirewound fixed inductor from TDK's NLFV series. It features an inductance of 3.3 µH with a tolerance of ±20%. The component supports a maximum rated current of 180 mA and has a maximum DC resistance (DCR) of 600 milliohms. Designed for surface mount installation, it measures 2.50mm x 2.00mm x 1.90mm. The inductor operates within a temperature range of -40°C to +105°C and utilizes a ferrite core material.

Fixed Inductors Feature Summary

• Shielded construction minimizes electromagnetic interference
• Drum core wirewound design for stable performance
• Suitable for decoupling circuit applications

Fixed Inductors Applications

• Decoupling circuits
• Power supply filtering
• Signal processing lines

Fixed Inductors Procurement Notes

Verify the specific part number against official TDK documentation to ensure accuracy. Confirm that the required inductance value and current ratings align with the design specifications. Check for RoHS compliance status if environmental regulations apply to the final assembly. Ensure the surface mount package dimensions fit the available PCB footprint.

Fixed Inductors Selection Notes

Select this component when a shielded inductor with low profile is required for space-constrained designs. Consider the 180 mA current rating and 600 mΩ DCR for power efficiency requirements. Compare against other NLFV series variants if different inductance values or current capabilities are needed. Verify thermal performance within the specified operating temperature range.

Fixed Inductors Part Context

This inductor belongs to the NLFV series, which focuses on compact, shielded solutions for modern electronics. The series offers various inductance options within the same mechanical footprint, facilitating design flexibility. It is intended for use in consumer electronics and industrial equipment requiring reliable passive components.

Fixed Inductors Replacement Considerations

Check for direct substitutes within the NLFV series with identical electrical parameters. Verify compatibility with existing PCB layouts before switching to alternative manufacturers' components.
