NNENCLJNNF-10.000000

Oscillators Overview

The NNENCLJNNF-10.000000 is a恒温晶体振荡器 (OCXO) manufactured by Taitien. It operates at a nominal frequency of 10.0000 MHz with CMOS output type and a supply voltage of 3.3V. The component features high frequency stability of ±20ppb and an operating temperature range from -40°C to 85°C. Physical dimensions are 9.70 x 7.50 mm, with a maximum supply current of 350mA.

Oscillators Feature Summary

• High precision frequency stability of ±20ppb
• CMOS output interface for digital compatibility
• Ultra-thin ceramic package design

Oscillators Applications

• Bluetooth devices
• Mobile phones
• Wireless LAN systems

Oscillators Procurement Notes

Verify the specific suffix and revision code against the official Taitien datasheet to ensure compatibility with required frequency tolerance and load capacitance specifications. Confirm that the 3.3V supply requirement aligns with the target circuit design before procurement.

Oscillators Selection Notes

Select this OCXO when ultra-high stability is critical for wireless communication applications. Ensure the PCB layout accommodates the 9.70 x 7.50 mm footprint and provides adequate thermal management for the 350mA current draw during operation within the specified temperature range.

Oscillators Part Context

This part belongs to Taitien's NN series of surface mount oscillators. It represents a specialized solution for applications requiring superior phase noise and frequency accuracy compared to standard TCXOs or crystals, leveraging oven-controlled technology for consistent performance.

Oscillators Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation. Direct replacement requires matching the 10MHz frequency, CMOS output, 3.3V supply, and physical dimensions.
