NSBA123JDP6T5G

Overview

The NSBA123JDP6T5G is a digital transistor from onsemi, classified as a pre-biased resistor transistor (PBRT). It integrates two PNP transistors with built-in bias resistors into a single surface-mount package. The device is designed to replace discrete components and external biasing networks, simplifying circuit design while reducing board space. Key electrical characteristics include a maximum collector-emitter voltage of 50V and a continuous collector current of 100mA. The component operates within a temperature range of -55°C to +150°C and features a typical input resistance of 2.2 kOhms.

Feature Summary

• Integrates dual PNP transistors with internal bias resistors to eliminate external components
• Designed for direct replacement of discrete transistor and resistor networks
• Supports surface-mount installation in compact packages

Applications

• General-purpose switching applications requiring dual PNP control
• Interface circuits replacing discrete biasing networks
• Embedded systems utilizing limited board space

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm pinout configuration and packaging type. Ensure compatibility with existing PCB footprints before procurement. Confirm RoHS compliance status through the latest datasheet or product compliance reports provided by onsemi.

Selection Notes

Select this component when a dual PNP configuration with integrated biasing is required. Verify that the 50V voltage rating and 100mA current capacity meet the circuit requirements. Compare the internal resistor values with the target application's base drive needs to ensure proper saturation levels.

Part Context

This part belongs to the NSBA series of pre-biased resistor transistors manufactured by onsemi. These devices are engineered to consolidate multiple discrete semiconductor functions into a single package, facilitating miniaturization in modern electronic designs.

Replacement Considerations

Check for equivalent parts such as NSBA123EDXV6T1 or NSBA123TF3T5G if pinout compatibility allows. Verify that substitute components match the required polarity, voltage ratings, and internal resistance values.
