NSBC114EPDXVT1G

Overview

The NSBC114EPDXVT1G is a dual NPN digital transistor manufactured by onsemi, housed in an SOT-563-6 surface-mount package. It integrates two NPN transistors with built-in bias resistor networks designed to replace discrete components and simplify circuit layouts. Key electrical specifications include a maximum collector-emitter voltage (VCEO) of 50 V and a continuous collector current of 100 mA. The device features a typical input resistance of 10 kOhms and a minimum DC current gain (hFE) of 80. Power dissipation is rated at 357 mW, with an operating temperature range spanning from -55°C to +150°C.

Feature Summary

• Integrates dual NPN transistors with monolithic bias resistor networks to reduce component count and board space.
• Simplifies circuit design by eliminating the need for external discrete biasing resistors.

Applications

• General-purpose switching applications requiring compact digital transistor solutions.
• Interface circuits where simplified biasing reduces assembly complexity.
• Embedded systems utilizing low-voltage logic control.

Procurement Notes

Verify the specific ordering suffix against official manufacturer documentation to confirm exact configuration and packaging details. Confirm RoHS compliance status directly with the supplier or datasheet, as availability and regulatory markings can vary by production batch and region. Ensure the component source is authorized to guarantee authenticity and traceability.

Selection Notes

Select this component when a dual NPN configuration with integrated biasing is required for space-constrained designs. Verify that the 50 V voltage rating and 100 mA current capacity meet the specific load requirements. Consider the SOT-563-6 package dimensions for PCB layout compatibility and ensure the thermal management strategy supports the specified power dissipation limits within the target operating temperature range.

Part Context

This part belongs to the NSBC series of complementary bipolar digital transistors produced by onsemi. These devices are engineered to consolidate multiple discrete components into a single package, thereby enhancing reliability and reducing manufacturing costs. The series typically includes various configurations of NPN and PNP transistors with different resistor values to suit diverse logic interface needs.

Replacement Considerations

Consult official substitution guides for verified equivalents. Cross-reference pinouts and electrical parameters carefully when considering alternative manufacturers' parts to ensure functional compatibility without redesigning the surrounding circuitry.
