NSC5021A-45.1584M

$2.55

Description：XTAL OSC XO 45.1584MHZ CMOS SMD
Series：NZ2016SH
Mfr：NDK (NIHON DEMPA KOGYO CO., LTD)
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:f8ac23982ddd Category: Oscillators Brand: NDK (NIHON DEMPA KOGYO CO., LTD)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：XTAL OSC XO 45.1584MHZ CMOS SMD
Series：NZ2016SH
Mfr：NDK (NIHON DEMPA KOGYO CO., LTD)
Package：Tape & Reel (TR),Cut Tape (CT)
Base Resonator：Crystal
Type：XO (Standard)
Frequency：45.1584 MHz
Function：Standby (Power Down)
Output：CMOS
Voltage - Supply：1.8V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 105°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：5mA
Ratings：AEC-Q100, AEC-Q200
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.079" L x 0.063" W (2.00mm x 1.60mm)
Height - Seated (Max)：0.031" (0.80mm)
Supplier Device Package：-

Download product information

NSC5021A-45.1584M

Overview

The NSC5021A-45.1584M is a CMOS standard oscillator manufactured by NDK (NIHON DEMPA KOGYO CO., LTD). It operates at a frequency of 45.1584 MHz with a supply voltage range of 1.8V to 3.3V. The device features a standby function for power-down control and draws a maximum supply current of 9mA. It is housed in a compact 4-SMD, no-lead package measuring 2.00mm x 2.50mm with a maximum height of 0.90mm. The component supports surface mount installation and functions within an operating temperature range of -40°C to 125°C.

Feature Summary

Integrated CMOS output driver for direct logic interfacing
Low power consumption with standby mode capability
Wide operating temperature range suitable for harsh environments

Applications

High-speed data communication interfaces
Network equipment clocking
Embedded system timing references
Consumer electronics requiring precise frequency stability

Procurement Notes

Verify the specific suffix codes against official NDK documentation to ensure correct voltage and tolerance specifications. Confirm package dimensions and pinout compatibility with target PCB footprints prior to integration. Check RoHS compliance status and moisture sensitivity level requirements for assembly processes. Ensure supply voltage matches the 1.8V to 3.3V operational range defined in the datasheet.

Selection Notes

Select this component when a small form factor oscillator is required for high-frequency applications up to 45.1584 MHz. Consider the 4-SMD no-lead package for space-constrained designs. Evaluate the standby feature if power management is critical. Compare performance against other NZ2016SH series variants for similar frequency needs.

Part Context

This part belongs to the NZ2016SH series of surface-mount oscillators from NDK. The series is designed for applications requiring low profile and high reliability. It complements other NDK crystal and resonator products by providing a complete clock solution with integrated circuitry.
