NSC5182D-27M

Overview

The NSC5182D-27M is a standard CMOS crystal oscillator manufactured by NDK. It operates at a frequency of 27 MHz and supports a supply voltage of 3.3V. The device features a standby function for power-down control. It utilizes a 4-SMD, No Lead package with dimensions of 3.20mm x 2.50mm. The component is designed for surface mount installation and is currently in active production.

Feature Summary

• Integrated CMOS output driver for direct logic interfacing
• Low-power standby mode capability for energy management
• Compact 4-SMD no-lead surface mount packaging

Applications

• Digital clock signal generation
• Microcontroller system timing
• Communication interface synchronization

Procurement Notes

Verify the specific operating voltage requirements against the target circuit design to ensure compatibility with the 3.3V specification. Confirm that the 27 MHz frequency aligns with the system's timing needs. Check the datasheet for drive level limitations and load capacitance requirements to guarantee stable oscillation. Ensure the PCB layout accommodates the 4-SMD footprint dimensions accurately.

Selection Notes

Select this component when a precise 27 MHz reference is required for digital systems. Consider the 3.3V supply constraint and the availability of a standby pin for power optimization. Evaluate the 4-SMD form factor against available board space. Compare performance metrics such as phase noise and stability if high-precision timing is critical for the application.

Part Context

This part belongs to NDK's series of standard CMOS oscillators. These devices provide reliable clock signals for various electronic applications. The NX3225SA series includes similar crystals, but this model is an integrated oscillator unit. It offers a complete solution compared to discrete crystal components.

Replacement Considerations

No public confirmed substitute part numbers are available in the provided documentation.
