Product Detailed Parameters
- Description：XTAL OSC XO 100MHZ HCSL 3.3V SMD
- Series：NP3225SC
- Mfr：NDK (NIHON DEMPA KOGYO CO., LTD)
- Package：Tape & Reel (TR),Cut Tape (CT)
- Base Resonator：Crystal
- Type：XO (Standard)
- Frequency：100 MHz
- Function：Standby (Power Down)
- Output：HCSL
- Voltage - Supply：3.3V
- Frequency Stability：±50ppm
- Absolute Pull Range (APR)：-
- Operating Temperature：-40°C ~ 105°C
- Spread Spectrum Bandwidth：-
- Current - Supply (Max)：50mA
- Ratings：AEC-Q200
- Mounting Type：Surface Mount
- Package / Case：6-SMD, No Lead
- Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max)：0.039" (1.00mm)
- Supplier Device Package：-
Download product information
Overview
The NSC5346B-100M is a standard crystal oscillator (XO) manufactured by NDK. It operates at a frequency of 100 MHz and utilizes HCSL output logic. The device functions within a 3.3V supply voltage range and features a shutdown capability for power management. It is housed in a compact 6-SMD, no-lead package designed for surface-mount assembly.
Feature Summary
- Integrates HCSL output logic for high-speed signal integrity
- Includes shutdown pin functionality for power optimization
- Supports 3.3V single-supply operation
Applications
- High-speed digital data transmission interfaces
- Clock generation for network communication equipment
- System clock sources for embedded processing units
Procurement Notes
Verify the specific output load requirements and termination resistor values compatible with HCSL standards during integration. Confirm that the 3.3V supply rail meets the current consumption specifications listed in the official datasheet to ensure stable oscillation. Check for any specific reflow soldering profile recommendations provided by NDK for the 6-SMD package.
Selection Notes
Select this component when a precise 100 MHz reference is required for systems utilizing HCSL signaling. Consider the shutdown feature if power efficiency is critical. Ensure the PCB layout accommodates the 6-SMD footprint and provides adequate thermal relief for the surface-mount package.
Part Context
This part belongs to NDK's series of standard crystal oscillators. It complements their portfolio of frequency control solutions, offering a fixed-frequency alternative to programmable devices. The HCSL variant is distinct from LVDS or CMOS outputs, targeting specific high-speed interface compatibility requirements in industrial and consumer electronics.
Replacement Considerations
ABM10-100.000MHZ-D30-T3
FAQ
What type of output logic does the NSC5346B-100M use?
It uses HCSL (Hybrid Current Mode Logic) output.
Does this oscillator support power-down modes?
Yes, it includes a shutdown function to disable the output and reduce power consumption.
