NT2016SF-38.4MHZ-END4848C

$1.14

Description：XTAL OSC VCTCXO 38.4000MHZ SMD
Series：NT2016SF
Mfr：NDK (NIHON DEMPA KOGYO CO., LTD)
Package：Tape & Reel (TR)

SKU:6ff386c33795 Category: Oscillators Brand: NDK (NIHON DEMPA KOGYO CO., LTD)

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：XTAL OSC VCTCXO 38.4000MHZ SMD
Series：NT2016SF
Mfr：NDK (NIHON DEMPA KOGYO CO., LTD)
Package：Tape & Reel (TR)
Base Resonator：Crystal
Type：VCTCXO
Frequency：38.4 MHz
Function：-
Output：Clipped Sine Wave
Voltage - Supply：1.8V
Frequency Stability：±3.6ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 105°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：1.7mA
Ratings：-
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.079" L x 0.063" W (2.00mm x 1.60mm)
Height - Seated (Max)：0.031" (0.80mm)
Supplier Device Package：-

Download product information

NT2016SF-38.4MHZ-END4848C

Overview

The NT2016SF-38.4MHZ-END4848C is a Voltage-Controlled Temperature-Compensated Crystal Oscillator (VCTCXO) manufactured by NDK. It operates at a frequency of 38.4 MHz with a clipped sine wave output. The device features a supply voltage range of 1.7 V to 3.6 V and consumes a maximum current of 15 mA. It offers a frequency stability of ±0.6 ppm over the temperature range of -40°C to +85°C. The unit is housed in a compact 4-SMD, no-lead package measuring 2.0 mm x 1.6 mm x 0.8 mm.

Feature Summary

Integrates voltage control for precise frequency tuning within oscillator circuits
Provides high frequency stability across wide industrial temperature ranges
Supports low-voltage operation suitable for portable electronic devices

Applications

Wireless communication modules requiring stable clock sources
Portable consumer electronics with space constraints
Industrial control systems needing reliable timing signals

Procurement Notes

Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status matches project requirements. Ensure ESD handling protocols are followed during storage and assembly. Check datasheet revisions for any recent parameter updates before finalizing design integration.

Selection Notes

Choose this component when a small footprint and low power consumption are critical alongside high frequency stability. Compare against standard TCXOs if voltage control functionality is not required. Evaluate thermal performance characteristics against specific application environments to ensure long-term reliability.

Part Context

This part belongs to NDK's NT2016SF series of surface-mount oscillators. The series is designed to replace discrete crystal and compensation circuits, offering a compact solution for modern electronics. It complements other NDK products like the NX2016SA crystals and NZ2520SHA oscillators in providing complete timing solutions.
