NX5P2924BUK012

Overview

The NX5P2924BUK012 is a logic-controlled high-side power distribution switch manufactured by Freescale Semiconductor. It features a single N-channel configuration capable of delivering a maximum output current of 2.5A. The device exhibits a typical on-resistance (Rds On) of 14mOhm, ensuring efficient power transmission with minimal voltage drop. It utilizes an inverting input type for control logic compatibility. Key functional attributes include integrated load discharge capabilities and slew rate control to manage switching transients. The component is housed in a compact 6-WLCSP package measuring 0.87x1.37 mm, suitable for space-constrained applications.

Feature Summary

• Logic-controlled high-side power switching with inverting input interface
• Integrated load discharge functionality for safe energy dissipation
• Slew rate controlled switching to minimize electromagnetic interference

Applications

• High-side power distribution in embedded systems
• Load driver circuits requiring controlled switching speeds
• Power management units with limited board space

Procurement Notes

Verify the manufacturer designation as Freescale Semiconductor or its successor NXP Semiconductors when sourcing components. Confirm the specific package variant matches the 6-WLCSP (0.87x1.37) footprint requirements for your PCB layout. Ensure that the inverting input logic levels are compatible with your system's control signals before integration.

Selection Notes

Select this component for applications requiring a compact high-side switch with precise control over switching speed. The 2.5A current rating and low on-resistance make it suitable for moderate power loads where thermal efficiency is critical. Consider the inverting input requirement when designing the control circuitry to ensure proper signal inversion if necessary.

Part Context

This part belongs to the family of logic-controlled power switches designed for reliable load management. Originally produced by Freescale Semiconductor, the product line continues under NXP Semiconductors following corporate acquisitions. These devices are engineered to provide robust protection and efficient power routing in electronic systems.

Replacement Considerations

Consult official substitution guides from NXP Semiconductors for verified equivalent parts. Cross-reference pinouts and electrical characteristics carefully to ensure compatibility with existing designs.
