NXV08V080DB1

Overview

The NXV08V080DB1 is a three-phase inverter module manufactured by onsemi. It belongs to the AC/DC converter product category and falls under PMIC - Power Management ICs. The component utilizes Silicon technology and features an APM-17 package configuration. It is designed for automotive applications, specifically motor drives and onboard chargers. The module supports half-bridge topology with integrated sense resistors.

Feature Summary

• Integrated three-phase inverter topology with battery disconnect switch capability
• Incorporates superjunction technology for enhanced switching performance
• Features built-in sense resistors for precise current monitoring
• Designed for high-reliability automotive environments

Applications

• Automotive motor drive systems
• Onboard charger (OBC) implementations
• Three-phase inverter circuits requiring integrated protection

Procurement Notes

Verify the specific ordering suffix and package variant against the official datasheet before procurement. Confirm RoHS compliance status and material composition details directly from the manufacturer's documentation. Ensure the selected part matches the required thermal and electrical specifications for the target application environment.

Selection Notes

Select this module when a compact three-phase inverter solution with integrated sensing is required. Consider the APM-17 package dimensions and mounting requirements during PCB layout. Evaluate the thermal dissipation capabilities relative to the expected load currents and ambient operating conditions to ensure reliable long-term operation.

Part Context

This component is part of onsemi's automotive MOSFET module portfolio, which includes various topologies such as six-pack, full bridge, and half-bridge configurations. These modules are engineered for electric vehicle powertrains and charging systems, leveraging silicon superjunction technology to optimize efficiency and power density in demanding automotive applications.

Replacement Considerations

Consult the official onsemi cross-reference guide for verified substitute part numbers. Ensure any replacement maintains compatibility with the APM-17 package footprint and meets the same voltage and current ratings.
