OCETGCJTNF-48.000000

Oscillators Overview

The OCETGCJTNF-48.000000 is a CMOS/TTL output clock oscillator manufactured by Taitien, operating at a nominal frequency of 48 MHz. It utilizes a crystal base resonator and features a standard XO type configuration. The device supports an enable/disable function and operates within a supply voltage range of 3.135 V to 3.465 V, typically centered at 3.3 V. It is designed for surface mount installation in a 4-SMD, no lead package with dimensions of 7.00mm x 5.00mm. The unit complies with RoHS standards and exhibits a frequency stability of ±25 ppm.

Oscillators Feature Summary

• CMOS/TTL output interface compatible with standard logic families
• Integrated enable and disable control functionality for power management
• Surface mount construction in a compact 4-SMD no lead package

Oscillators Applications

• General purpose digital system clock generation
• Embedded controller timing references
• Communication interface synchronization

Oscillators Procurement Notes

Verify the specific suffix codes against the manufacturer's official numbering guide to ensure correct voltage, stability, and packaging specifications. Confirm that the requested variant matches the required operating temperature range and output load requirements. Cross-reference the part number with the latest datasheet to validate current production status and compliance certifications before finalizing procurement orders.

Oscillators Selection Notes

Select this component when a stable 48 MHz reference signal is required for CMOS-based digital circuits. Ensure the design accommodates the specified 3.3V supply tolerance and the maximum supply current rating. Consider the physical footprint constraints of the 7.00mm x 5.00mm package during PCB layout planning. Verify that the application environment remains within the defined operational temperature limits for optimal frequency stability.

Oscillators Part Context

This oscillator belongs to Taitien's OC series of surface mount crystal oscillators. The series provides standardized timing solutions for various electronic applications. The model designation indicates a 48 MHz frequency output with CMOS logic levels. The product line emphasizes reliability and compliance with international environmental standards for modern electronics manufacturing.

Oscillators Replacement Considerations

Direct substitutes include other 48 MHz CMOS oscillators in 4-SMD packages from Taitien such as OCETDCJTNF-48.000000 or OCETDLJTNF-48.000000, provided they meet identical electrical and mechanical specifications.
