OMI-SH-248L,594

OMI-SH-248L,594 is listed in the Power Relays, Over 2 Amps range at ChipApex. The manufacturer field lists TE Connectivity Potter & Brumfield Relays. Its product description is RELAY GEN PURPOSE DPDT 5A 48V. Review the specifications below when checking this part for your BOM.

Power Relays, Over 2 Amps specifications for OMI-SH-248L,594

• Description：RELAY GEN PURPOSE DPDT 5A 48V
• Series：OMI, OEG
• Mfr：TE Connectivity Potter & Brumfield Relays
• Package：Bulk
• Mounting Type：Through Hole
• Coil Voltage：48VDC
• Contact Form：DPDT (2 Form C)
• Contact Rating (Current)：5:00 AM
• Switching Voltage：250VAC, 30VDC - Max
• Load - Max Switching：1250VA, 150W
• Coil Current：11.3 mA
• Coil Type：Non Latching
• Features：-
• Termination Style：PC Pin
• Seal Rating：Sealed - Fully
• Coil Insulation：Class A
• Must Operate Voltage：36 VDC
• Must Release Voltage：2.4 VDC
• Operating Temperature：-30°C ~ 70°C
• Contact Material：Silver Tin Oxide (AgSnO)
• Approval Agency：CQC, CSA, UR, VDE
• Relay Type：General Purpose
• Grade：-
• Qualification：-
• Operate Time：20 ms
• Release Time：8 ms

Power Relays, Over 2 Amps datasheet and documents for OMI-SH-248L,594
