OPA2863AIDSNR

Instrumentation, Op Amps, Buffer Amps Overview

The OPA2863AIDSNR is a dual, high-precision, low-power operational amplifier from the OPAx863A family. It features a gain-bandwidth product of 50MHz and a slew rate of 100V/µs with rail-to-rail input and output capabilities. The device operates on supply voltages ranging from 2.7V to 12.6V. Key electrical specifications include a maximum input offset voltage of 95µV, an offset drift of 1.2µV/°C, and a quiescent current of 800µA per channel. It provides excellent harmonic distortion performance and includes overload power limiting and short-circuit protection.

Instrumentation, Op Amps, Buffer Amps Feature Summary

• High precision with trimmed input offset voltage and minimal drift for accurate measurements
• Rail-to-rail input and output stages enable full dynamic range operation across the entire supply voltage
• Integrated overload power limiting prevents excessive power dissipation during saturated output conditions
• Low quiescent current consumption supports extended battery life in portable applications

Instrumentation, Op Amps, Buffer Amps Applications

• Low-power SAR and ΔΣ ADC driver
• ADC reference buffer
• Photodiode TIA interface
• Battery-powered instrumentation

Instrumentation, Op Amps, Buffer Amps Procurement Notes

Verify the specific package type DSN (USON, 10) matches your PCB footprint requirements. Confirm that the operating temperature range of –40°C to +125°C aligns with your environmental constraints. Ensure proper handling procedures are followed due to moisture sensitivity classification. Cross-reference the datasheet revision date to ensure compatibility with your design documentation.

Instrumentation, Op Amps, Buffer Amps Selection Notes

Select this component when high DC accuracy is required alongside moderate bandwidth. The low offset voltage and drift make it suitable for precision signal conditioning. Consider the USON package size if board space is limited compared to standard SOIC or VSSOP options. Evaluate the power-down feature if system standby current reduction is necessary.

Instrumentation, Op Amps, Buffer Amps Part Context

This part belongs to the OPAx863A series, which includes single (OPA863A) and dual (OPA2863A) variants. The 'A' suffix indicates high-precision trimming. The 'DSNR' suffix denotes the Dual channel configuration in a 10-pin USON package supplied in a reel format. Other packages available include SOIC-8 and VSSOP-8.

Instrumentation, Op Amps, Buffer Amps Replacement Considerations

Direct pin-compatible replacements within the same family include OPA2863ADGKR (VSSOP-8) and OPA2863ADR (SOIC-8). Verify package dimensions and thermal characteristics when substituting between different package types.
