OSCAR40/5M/LL/SMAM/S/S/33 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Siretta Ltd. Its product description is RF ANT 880MHZ/2.2GHZ WHIP STR. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for OSCAR40/5M/LL/SMAM/S/S/33
- Description：RF ANT 880MHZ/2.2GHZ WHIP STR
- Series：OSCAR 40
- Mfr：Siretta Ltd
- Package：Bulk
- RF Family/Standard：802.15.4, Bluetooth, Cellular, General ISM, WiFi
- Frequency Group：Wide Band
- Frequency (Center/Band)：-
- Frequency Range：433MHz ~ 5.8GHz
- Antenna Type：Whip, Straight
- Number of Bands：2
- VSWR：1.5
- Return Loss：-
- Gain：5.5dBi
- Features：-
- Termination：SMA Male
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Pole Mount, Wall Mount
- Height (Max)：9.449" (240.00mm)
- Applications：802.11n/ac/ax, Bluetooth, LoRa, NB-IOT, Wi-Fi, WLAN, Sigfox, Zigbee™
- Power - Max：-
Antennas RF datasheet and documents for OSCAR40/5M/LL/SMAM/S/S/33
Antennas RF Overview
The Siretta OSCAR40/5M/LL/SMAM/S/S/33 is a multi-band whip antenna designed for broadband RF applications. It operates across frequency ranges of 698 MHz to 2.7 GHz and up to 5.85 GHz, supporting standards such as ZigBee and IEEE 802.15.4. The unit features a 5-meter cable length with an SMA male connector. Key electrical parameters include a gain of 5.5 dBi, a VSWR of 1.5, and an impedance of 50 ohms. The antenna utilizes a straight whip form factor with bracket mounting capabilities.
Antennas RF Feature Summary
- UV and water-resistant radome construction for outdoor durability
- Multi-band coverage supporting cellular, WLAN, and IoT protocols
- Straight whip design with integrated bracket mounting
Antennas RF Applications
- ZigBee network infrastructure
- IEEE 802.15.4 wireless sensor networks
- WLAN connectivity solutions
Antennas RF Procurement Notes
Verify the specific model suffix against the required frequency bands and cable length before ordering. Confirm that the SMA male connector polarity matches the receiving equipment interface. Ensure the bracket mounting hardware is compatible with the installation environment. Cross-reference the manufacturer datasheet for precise mechanical dimensions and environmental ratings.
Antennas RF Selection Notes
Select this component when broad frequency coverage from sub-GHz to 5 GHz is required in a single unit. The 5-meter cable provides flexibility for remote placement relative to the radio module. The high gain specification suits applications needing extended range or improved signal penetration compared to standard low-gain alternatives.
Antennas RF Part Context
This part belongs to the OSCAR 40 series, which focuses on high-performance multi-band antennas. The series typically offers robust environmental sealing and standardized connectors. It complements other Siretta products like the ALPHA and TANGO series by providing specialized whip-form factors for different mounting constraints.
Antennas RF Replacement Considerations
Public confirmed substitute part numbers are not available in the provided documentation. Verify compatibility with existing system designs before considering alternative models from the same manufacturer.
