OVLAB6CB8

LED Indication - Discrete Overview

The OVLAB6CB8 is a through-hole amber LED manufactured by TT Electronics/Optek Technology. It features a diffused lens for uniform light output and operates at a forward current of 20 mA with a typical forward voltage of 2.1 V. The component emits amber light at a peak wavelength of 590 nm, delivering a luminous intensity of 1400 mcd. It has a viewing angle of 65 degrees and is housed in a radial package measuring 3 mm in diameter.

LED Indication - Discrete Feature Summary

• Diffused lens design ensures uniform light distribution
• Radial through-hole construction for standard PCB assembly
• Amber emission color optimized for visibility

LED Indication - Discrete Applications

• Indicator lights for electronic equipment
• Status display in control panels
• Visual signaling in instrumentation

LED Indication - Discrete Procurement Notes

Verify the specific suffix against official manufacturer documentation to confirm exact optical characteristics and pin configuration. Ensure compatibility with existing thermal management requirements during soldering processes. Cross-reference datasheet revisions to confirm compliance with current environmental directives and material specifications before finalizing procurement.

LED Indication - Discrete Selection Notes

Select this component when a visible amber indicator is required for through-hole mounting applications. Consider the 65-degree viewing angle and diffused lens properties for applications needing wide-area visibility without glare. Evaluate the 20 mA operating current against available drive circuitry capabilities to ensure proper brightness levels are achieved within power constraints.

LED Indication - Discrete Part Context

This part belongs to the Optek Technology line of discrete LEDs, specifically designed for general-purpose indication. The product series utilizes standard radial lead configurations compatible with automated insertion machines. It represents a standard offering for visual status monitoring in consumer and industrial electronics where amber illumination is specified.

LED Indication - Discrete Replacement Considerations

Consult official substitution guides for direct equivalents. Verify that any alternative maintains identical forward voltage, current ratings, and mechanical dimensions to ensure board compatibility.
