OWISFT0905-102

Common Mode Chokes Overview

The OWISFT0905-102 is a two-line common mode choke manufactured by Ole Wolff Electronics Inc. It features a surface mount design with an inductance of 1 mH measured at 100 kHz. The component supports a current rating of 800 mA and exhibits a DC resistance (DCR) of 310 mOhm. Impedance is specified at 5 kOhms when tested at 5 MHz. The device is rated for operation up to a maximum temperature of +125°C.

Common Mode Chokes Feature Summary

• Provides common mode noise suppression for dual-line circuits
• Designed for surface mount assembly processes
• Engineered for high-frequency interference attenuation

Common Mode Chokes Applications

• Consumer electronics signal line filtering
• Medical device circuit protection
• Industrial system data interface noise reduction

Common Mode Chokes Procurement Notes

Verify the complete part number including suffixes against official manufacturer documentation to ensure correct impedance and current ratings. Confirm package dimensions and terminal configuration match the target PCB footprint. Check for RoHS compliance status if required by specific regulatory standards. Validate operating temperature range suitability for the intended environment.

Common Mode Chokes Selection Notes

Select this component based on the required 1 mH inductance value and 800 mA current handling capability. Ensure the 310 mOhm DCR meets power loss constraints within the circuit design. Verify that the 5 kOhm impedance at 5 MHz aligns with the targeted noise frequency spectrum. Confirm surface mount compatibility with available assembly equipment.

Common Mode Chokes Part Context

This component belongs to the Ole Wolff Electronics common mode filter choke series, which includes variants such as the OWISFT0905-202 and OWICM1006T-121. The manufacturer specializes in acoustic and magnetic components for consumer, medical, and industrial sectors. This specific model utilizes a standard SMD-4 package configuration typical for compact electronic assemblies.

Common Mode Chokes Replacement Considerations

Cross-reference with OWISFT0905-202 for similar form factor applications requiring different inductance values. Evaluate OWICM1006T-121 for designs needing higher current capacity with lower inductance. Verify pinout and dimensional compatibility before substituting any alternative common mode chokes.
