P3519-684J

$1.61

Description：FIXED IND 680UH 150MA 13.6OHM SM
Series：P3519
Mfr：Delevan
Package：Tape & Reel (TR)

SKU:95170e454e52 Category: Fixed Inductors Brand: Delevan

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

P3519-684J is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Delevan. Its product description is FIXED IND 680UH 150MA 13.6OHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for P3519-684J

Description：FIXED IND 680UH 150MA 13.6OHM SM
Series：P3519
Mfr：Delevan
Package：Tape & Reel (TR)
Type：-
Material - Core：Ferrite
Inductance：680 µH
Tolerance：±5%
Current Rating (Amps)：150 mA
Current - Saturation (Isat)：170mA
Shielding：Unshielded
DC Resistance (DCR)：13.6Ohm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-55°C ~ 130°C
Inductance Frequency - Test：10 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.358" L x 0.190" W (9.09mm x 4.83mm)
Height - Seated (Max)：0.185" (4.70mm)
Features：-

Fixed Inductors datasheet and documents for P3519-684J

P3519-684J

Fixed Inductors Overview

The Delevan P3519-684J is a fixed power inductor designed for surface mount applications. It features an unshielded construction with a ferrite core and standard SMD/SMT termination. The component provides an inductance of 680 µH with a tolerance of ±5%. It supports a maximum DC current of 150 mA and has a maximum DC resistance of 13.6 Ohms. The device operates within a temperature range of -55°C to +125°C.

Fixed Inductors Feature Summary

Surface mount design for PCB integration
Unshielded ferrite core construction
Standard SMD/SMT termination style

Fixed Inductors Applications

Power supply circuits
General electronic equipment filtering

Fixed Inductors Procurement Notes

Verify the specific manufacturer designation, as API Delevan assets are often managed by other entities. Confirm RoHS compliance status directly with the supplier, as documentation indicates non-compliance in some records. Ensure the unshielded configuration aligns with electromagnetic interference requirements for the target application before finalizing procurement.

Fixed Inductors Selection Notes

Select this component when a high-inductance value of 680 µH is required in a compact surface mount footprint. Consider the low current rating of 150 mA and high DC resistance of 13.6 Ohms during circuit design. The unshielded nature necessitates careful layout planning to manage magnetic field interactions with nearby components.

Fixed Inductors Part Context

This part belongs to the P3519 series of fixed inductors from Delevan. These components are categorized under power inductors and chokes. The series utilizes ferrite cores and offers various inductance values. The P3519-684J specifically targets applications requiring moderate inductance with standard surface mount processing capabilities.
