P4KE400CA-HF

P4KE400CA-HF is listed in the Tvs Diodes range at ChipApex. The manufacturer field lists Comchip Technology. Its product description is TVS DIODE 342VWM 552VC DO41. Review the specifications below when checking this part for your BOM.

Tvs Diodes specifications for P4KE400CA-HF

• Description：TVS DIODE 342VWM 552VC DO41
• Series：P4KE-HF
• Mfr：Comchip Technology
• Package：Tape & Box (TB)
• Type：Zener
• Bidirectional Channels：1
• Voltage - Reverse Standoff (Typ)：342V
• Voltage - Breakdown (Min)：380V
• Voltage - Clamping (Max) @ Ipp：552V
• Current - Peak Pulse (10/1000µs)：720mA
• Power - Peak Pulse：400W
• Power Line Protection：No
• Applications：General Purpose
• Capacitance @ Frequency：-
• Operating Temperature：-55°C ~ 150°C (TJ)
• Mounting Type：Through Hole
• Package / Case：DO-204AL, DO-41, Axial
• Supplier Device Package：DO-41
• Unidirectional Channels：-
• Grade：-
• Qualification：-

Tvs Diodes datasheet and documents for P4KE400CA-HF
