PA0512.151NL is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 150NH 24A 0.32MOHM SMD. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for PA0512.151NL
- Description：FIXED IND 150NH 24A 0.32MOHM SMD
- Series：PA0512NL
- Mfr：Pulse Electronics
- Package：Tray
- Type：-
- Material - Core：-
- Inductance：150 nH
- Tolerance：±20%
- Current Rating (Amps)：24 A
- Current - Saturation (Isat)：30A
- Shielding：Shielded
- DC Resistance (DCR)：0.32mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 130°C
- Inductance Frequency - Test：-
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.276" L x 0.276" W (7.00mm x 7.00mm)
- Height - Seated (Max)：0.195" (4.96mm)
- Features：-
Fixed Inductors datasheet and documents for PA0512.151NL
Fixed Inductors Overview
The PA0512.151NL is a shielded surface-mount power inductor from the PA0512NL series by Pulse Electronics. It features an inductance of 150 nH with a tolerance of ±20%. The component has a maximum DC current rating of 24 A and a saturation current of 30 A. Its maximum DC resistance (DCR) is 0.32 mOhm. The physical dimensions are 7.00 mm in length, 7.00 mm in width, and a maximum height of 4.96 mm. It operates within a temperature range of -40°C to +130°C.
Fixed Inductors Feature Summary
- Shielded construction for magnetic field containment
- High-current capability suitable for multi-phase applications
- Surface mount package design
Fixed Inductors Applications
- Multi-phase voltage regulator modules
- Point-of-load conversion circuits
- High-frequency power supply filtering
Fixed Inductors Procurement Notes
Verify the specific part number suffix against official documentation to ensure correct packaging and specifications. Confirm that the required inductance value and current ratings align with the circuit design requirements before procurement. Check for RoHS compliance status if environmental regulations apply to the manufacturing process.
Fixed Inductors Selection Notes
Select this component when low inductance and high current handling are required in a compact footprint. Ensure the PCB layout supports the specified surface mount dimensions. Verify thermal management capabilities as the component dissipates heat proportional to the square of the current and its DC resistance.
Fixed Inductors Part Context
This component belongs to the PA0512NL series of power beads designed for high-current applications. It is manufactured by Pulse Electronics and is classified as a fixed inductor. The series is optimized for efficiency in power delivery networks where space constraints and high current density are critical factors.
Fixed Inductors Replacement Considerations
PA0512.101NLT
Fixed Inductors FAQ
What is the saturation current of the PA0512.151NL?
The saturation current is 30 A.
Is the PA0512.151NL shielded?
Yes, it is a shielded power inductor.
