PA2982.121HL

$0.66

Description：FIXED IND 120NH 62A 0.35MOHM SMD
Series：PA2982.XXXHL
Mfr：Pulse Electronics
Package：Tray

SKU:27690ef870a4 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PA2982.121HL is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 120NH 62A 0.35MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PA2982.121HL

Description：FIXED IND 120NH 62A 0.35MOHM SMD
Series：PA2982.XXXHL
Mfr：Pulse Electronics
Package：Tray
Type：-
Material - Core：-
Inductance：120 nH
Tolerance：±10%
Current Rating (Amps)：62 A
Current - Saturation (Isat)：74A
Shielding：Shielded
DC Resistance (DCR)：0.35mOhm
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 130°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.433" L x 0.315" W (11.00mm x 8.00mm)
Height - Seated (Max)：0.201" (5.10mm)
Features：-

Fixed Inductors datasheet and documents for PA2982.121HL

PA2982.121HL

Fixed Inductors Overview

The PA2982.121HL is a fixed shielded surface-mount inductor from Pulse Electronics, rated at 120 nH with a ±10% tolerance. It supports a maximum DC current of 62 A and a saturation current of 48 A, featuring a low DC resistance of 0.35 mΩ. The component measures 11.00 mm x 8.00 mm x 5.10 mm max and operates within a temperature range of -40°C to 130°C. Tested at 100 kHz, it utilizes a non-standard package suitable for high-current applications.

Fixed Inductors Feature Summary

High current handling capability with a 62 A rating and 48 A saturation threshold
Shielded construction minimizes electromagnetic interference
Low DC resistance of 0.35 mΩ for efficient power delivery
Wide operating temperature range from -40°C to 130°C

Fixed Inductors Applications

Power supply output filtering
DC-DC converter input/output stages
High-current point-of-load regulation

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against the official datasheet to ensure correct packaging and specifications. Confirm RoHS compliance status and moisture sensitivity level requirements prior to integration. Cross-reference the manufacturer part number with authorized distributors to validate authenticity and traceability. Ensure storage conditions align with the specified humidity sensitivity等级.

Fixed Inductors Selection Notes

Select this component when high current capacity and compact shielding are required. The 120 nH value suits high-frequency switching applications. Evaluate thermal management needs given the 130°C maximum rating. Compare physical dimensions against PCB layout constraints. Consider the trade-off between saturation current and DC resistance for efficiency optimization.

Fixed Inductors Part Context

This part belongs to the PA2982.XXXHL series of fixed inductors from Pulse Electronics. The series offers various inductance values within a consistent form factor. These components are designed for robust performance in demanding power electronics environments. The PA2982.121HL specifically targets applications requiring significant current handling in a small footprint.
