PA4342.252NLT

$0.83

Description：FIXED IND 2.5UH 11.5A 8.7MOHM SM
Series：PA4342.XXXNLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:c4c431e32816 Category: Fixed Inductors Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PA4342.252NLT is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is FIXED IND 2.5UH 11.5A 8.7MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PA4342.252NLT

Description：FIXED IND 2.5UH 11.5A 8.7MOHM SM
Series：PA4342.XXXNLT
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Type：Molded
Material - Core：-
Inductance：2.5 µH
Tolerance：±20%
Current Rating (Amps)：11.5 A
Current - Saturation (Isat)：23A
Shielding：Shielded
DC Resistance (DCR)：8.7mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-40°C ~ 125°C
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.453" L x 0.406" W (11.50mm x 10.30mm)
Height - Seated (Max)：0.157" (4.00mm)
Features：-

Fixed Inductors datasheet and documents for PA4342.252NLT

PA4342.252NLT

Fixed Inductors Overview

The PA4342.252NLT is a fixed surface-mount power inductor from Pulse Electronics, designed for high-current applications. It features a shielded molded construction with an inductance of 2.5 µH and a tolerance of ±20%. The component supports a maximum DC current of 11.5 A and a saturation current of 23 A. Its maximum DC resistance is 8.7 mΩ. Measuring 11.50 mm x 10.30 mm x 4.00 mm, it operates within a temperature range of -40°C to 125°C and holds AEC-Q200 qualification.

Fixed Inductors Feature Summary

Shielded molded design minimizes electromagnetic interference
AEC-Q200 qualified for automotive reliability standards
High saturation current capability for robust performance

Fixed Inductors Applications

Automotive battery management systems
High current power supply circuits
DC-DC converter output filtering

Fixed Inductors Procurement Notes

Verify the specific manufacturer part number against official Pulse Electronics documentation to ensure accuracy. Confirm that the component meets all required electrical specifications for your application. Check for any recent updates to the datasheet or compliance certifications before finalizing procurement decisions.

Fixed Inductors Selection Notes

Select this component when a compact, shielded inductor with high current handling is required. Ensure the PCB footprint matches the nonstandard package dimensions. Verify that the thermal environment allows operation within the specified temperature range and that the saturation current exceeds peak load requirements.

Fixed Inductors Part Context

This part belongs to the PA4342.XXXNLT series of SMD power inductors. The series offers various inductance values tailored for different current requirements while maintaining a consistent low-profile footprint. These components are engineered for space-constrained designs requiring reliable magnetic shielding.
