PAC6034.105NLT

Common Mode Chokes Overview

The PAC6034.105NLT is a surface-mount common mode choke from Pulse Electronics, designed for two-line signal filtering applications. It features a compact SMD package with dimensions of 7.8 mm in length, 4.4 mm in width, and 2.6 mm in height. The component provides an impedance of 7.8 kOhms at a frequency of 2.6 MHz. It supports a maximum DC current rating of 2.1 A and exhibits a maximum DC resistance (DCR) of 85 mOhms. The device operates within a temperature range of -55°C to +125°C and is suitable for commercial applications.

Common Mode Chokes Feature Summary

• Provides effective common mode noise suppression for two-line circuits
• Utilizes a low-profile surface-mount design for space-constrained layouts
• Constructed with molded core technology for mechanical stability

Common Mode Chokes Applications

• Commercial electronic equipment signal line filtering
• High-speed data interface noise suppression
• General-purpose EMI/RFI mitigation in consumer electronics

Common Mode Chokes Procurement Notes

Verify the specific ordering suffix against the manufacturer's latest datasheet to ensure correct impedance and current ratings. Confirm that the package dimensions and terminal configuration match the target PCB footprint requirements. Check for any recent Product Change Notifications (PCNs) regarding material or manufacturing site updates to ensure continuity with existing designs.

Common Mode Chokes Selection Notes

Select this component when a low-profile solution is required for two-line filtering in commercial-grade environments. Ensure the operating current does not exceed the 2.1 A rating to maintain performance. Verify that the 7.8 kOhm impedance at 2.6 MHz aligns with the specific noise frequencies present in the application circuit.

Common Mode Chokes Part Context

This part belongs to the PAC6034.XXXNLT series of surface-mount common mode chokes manufactured by Pulse Electronics. The series offers various impedance options tailored for different filtering needs while maintaining a consistent physical footprint. These components are widely used in commercial electronics where space efficiency and reliable noise suppression are critical design factors.

Common Mode Chokes Replacement Considerations

Consult official substitution lists for direct equivalents. Cross-reference impedance values and current ratings carefully when considering alternative manufacturers. Verify package compatibility before replacing.
