PBC01DBBN

Headers, Male Pins Overview

The PBC01DBBN is a dual-row male header connector manufactured by Sullins Connector Solutions. It features a .100 inch (2.54mm) centerline spacing and contains two positions per row, totaling four contacts. The connector utilizes phosphor bronze contacts with a 100.0µin (2.54µm) gold plating finish. Designed for through-hole mounting, it supports a current rating of 3 Amps. The insulator material meets UL 94V-0 flammability standards.

Headers, Male Pins Feature Summary

• Dual-row configuration with breakaway capability for flexible board length selection
• Through-hole termination method ensures secure PCB attachment
• Gold-plated phosphor bronze contacts provide reliable electrical conductivity

Headers, Male Pins Applications

• General purpose electronic circuit interconnections
• Prototype development boards requiring breakaway headers
• Industrial control system signal routing

Headers, Male Pins Procurement Notes

Verify the specific contact finish thickness and insulator material composition against the official manufacturer datasheet prior to procurement. Confirm that the through-hole mounting style aligns with your printed circuit board design requirements. Ensure compatibility with mating female connectors regarding pin pitch and row alignment to prevent assembly errors.

Headers, Male Pins Selection Notes

Select this component when a low-profile, dual-row male header with breakaway functionality is required. The .100 inch spacing accommodates standard wire gauges and common mating connectors. Consider the 3 Amp current rating for power distribution needs. Verify that the right-angle orientation fits within the mechanical constraints of the target enclosure or assembly layout.

Headers, Male Pins Part Context

This part belongs to the PBC series of rectangular connectors from Sullins Connector Solutions. The series offers various configurations including straight and right-angle options in single and dual rows. The PBC01DBBN specifically addresses applications needing a compact, two-position dual-row solution with robust through-hole connectivity and breakaway features for custom sizing.

Headers, Male Pins Replacement Considerations

Direct substitutes include other Sullins PBC series right-angle dual headers with matching .100 inch spacing and two positions. Verify that alternative parts maintain identical current ratings and contact materials. Ensure mechanical dimensions and mounting hole patterns are compatible with existing PCB footprints before substitution.
