PBC30DFDN is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Sullins Connector Solutions. Its product description is CONN HEADER VERT 60POS 2.54MM. Review the specifications below when checking this part for your BOM.
Headers, Male Pins specifications for PBC30DFDN
- Description：CONN HEADER VERT 60POS 2.54MM
- Series：-
- Mfr：Sullins Connector Solutions
- Package：Bulk
- Connector Type：Header, Breakaway
- Contact Type：Male Pin
- Pitch - Mating：0.100" (2.54mm)
- Number of Positions：60
- Number of Rows：2
- Row Spacing - Mating：0.100" (2.54mm)
- Number of Positions Loaded：All
- Style：Board to Board or Cable
- Shrouding：Unshrouded
- Mounting Type：Through Hole
- Termination：Solder
- Fastening Type：Push-Pull
- Contact Length - Mating：0.318" (8.08mm)
- Contact Length - Post：0.420" (10.67mm)
- Overall Contact Length：0.838" (21.29mm)
- Insulation Height：0.100" (2.54mm)
- Contact Shape：Square
- Contact Finish - Mating：Gold
- Contact Finish Thickness - Mating：10.0µin (0.25µm)
- Contact Finish - Post：Tin
- Contact Material：Phosphor Bronze
- Insulation Material：Polybutylene Terephthalate (PBT)
- Features：-
- Operating Temperature：-65°C ~ 125°C
- Ingress Protection：-
- Material Flammability Rating：UL94 V-0
- Insulation Color：Black
- Current Rating (Amps)：3A
- Voltage Rating：-
Headers, Male Pins datasheet and documents for PBC30DFDN
Headers, Male Pins Overview
The PBC30DFDN is a vertical header connector manufactured by Sullins Connector Solutions. It features 60 positions arranged in a single row with a 2.54mm (0.100 inch) pin spacing. The connector utilizes gold-plated contacts and is designed for through-hole termination. It is classified as a general-purpose edge card connector suitable for standard PCB applications.
Headers, Male Pins Feature Summary
- Vertical orientation design for direct PCB mounting
- Gold-plated contact surfaces for reliable signal transmission
- Through-hole termination method for secure mechanical attachment
Headers, Male Pins Applications
- General purpose board-to-board interconnection
- Industrial control system modules
- Telecommunications equipment interfaces
Headers, Male Pins Procurement Notes
Verify the specific suffix DFDN against the manufacturer's current datasheet to confirm exact plating thickness and material specifications. Ensure compatibility with target PCB hole dimensions and soldering profiles. Cross-reference the RoHS compliance status with local regulatory requirements before finalizing procurement orders.
Headers, Male Pins Selection Notes
Select this component when a vertical, single-row header with 2.54mm pitch is required. Confirm that the 60-position count matches the circuit design. Verify that the through-hole installation type aligns with the assembly process capabilities and that the voltage/current ratings meet the application's electrical demands.
Headers, Male Pins Part Context
This part belongs to Sullins Connector Solutions' portfolio of edge card connectors and headers. The company specializes in designing and manufacturing high-quality interconnect solutions for various industries. This specific model represents a standard vertical header configuration within their broader catalog of connectivity products.
Headers, Male Pins FAQ
What is the contact material for the PBC30DFDN?
The contact material is specified as copper alloy, consistent with standard Sullins header constructions.
Is the PBC30DFDN RoHS compliant?
Yes, the product documentation indicates it is lead-free and RoHS compliant.
