PC0503-1R0M-RC is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Allied Components International. Its product description is 1.0uH +/-20% Power Chip Inductor. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for PC0503-1R0M-RC
- Description：1.0uH +/-20% Power Chip Inductor
- Series：-
- Mfr：Allied Components International
- Package：Tape & Reel (TR)
- Type：Wirewound
- Material - Core：-
- Inductance：1 µH
- Tolerance：±20%
- Current Rating (Amps)：4.5 A
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：30mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 85°C
- Inductance Frequency - Test：7.96 MHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.228" L x 0.205" W (5.80mm x 5.20mm)
- Height - Seated (Max)：0.130" (3.30mm)
- Features：-
Fixed Inductors datasheet and documents for PC0503-1R0M-RC
Fixed Inductors Overview
The PC0503-1R0M-RC is a fixed power inductor manufactured by Allied Components International. It features a wirewound construction with an inductance of 1.0 µH and a tolerance of ±20%. The component has a direct current resistance (DCR) of 30 milli-ohms. It utilizes a non-standard surface-mount package designated as 0503 metric. The device is currently in active production status.
Fixed Inductors Feature Summary
- Wirewound construction for stable inductance performance
- Shielded design to minimize electromagnetic interference
- Surface-mount form factor for automated assembly
Fixed Inductors Applications
- DC-DC converter input filtering
- Output filtering in point-of-load modules
- General-purpose power supply circuits
Fixed Inductors Procurement Notes
Verify the specific datasheet version for the PC0503-1R0M-RC to confirm exact thermal ratings and saturation current limits, as these parameters are critical for circuit reliability. Ensure the ordering suffix matches the required tape and reel packaging configuration. Cross-reference the manufacturer's latest documentation to validate RoHS compliance status before finalizing procurement specifications.
Fixed Inductors Selection Notes
Select this component when a low-inductance value of 1.0 µH is required for high-frequency switching applications. The low DCR of 30 milli-ohms supports efficient power transfer with minimal resistive losses. Consider the physical dimensions of the 0503 metric package to ensure compatibility with the printed circuit board layout constraints and available mounting space.
Fixed Inductors Part Context
This part belongs to the PC0503 series of fixed power inductors from Allied Components International. The series offers various inductance values tailored for different power management needs. The PC0503-1R0M-RC specifically addresses requirements for compact, low-inductance filtering in modern electronic devices where space efficiency and electrical performance are prioritized.
Fixed Inductors Replacement Considerations
Consult the official datasheet for electrically equivalent alternatives within the same series or from other manufacturers. Verify that any substitute part maintains compatible inductance, tolerance, current ratings, and physical footprint dimensions to ensure seamless integration without redesigning the host circuit board.
