PC357N7TJ00F

$0.88

Description：OPTOISO 3.75KV TRANS 4-MINI-FLAT
Series：-
Mfr：Sharp Microelectronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:9e40d1b7166a Category: Transistor, Photovoltaic Output Optoisolators Brand: Sharp Microelectronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PC357N7TJ00F is listed in the Transistor, Photovoltaic Output Optoisolators range at ChipApex. The manufacturer field lists Sharp Microelectronics. Its product description is OPTOISO 3.75KV TRANS 4-MINI-FLAT. Review the specifications below when checking this part for your BOM.

Transistor, Photovoltaic Output Optoisolators specifications for PC357N7TJ00F

Description：OPTOISO 3.75KV TRANS 4-MINI-FLAT
Series：-
Mfr：Sharp Microelectronics
Package：Tape & Reel (TR),Cut Tape (CT)
Number of Channels：1
Voltage - Isolation：3750Vrms
Current Transfer Ratio (Min)：200% @ 5mA
Current Transfer Ratio (Max)：600% @ 5mA
Turn On / Turn Off Time (Typ)：-
Rise / Fall Time (Typ)：4µs, 3µs
Input Type：DC
Output Type：Transistor
Voltage - Output (Max)：80V
Current - Output / Channel：50mA
Voltage - Forward (Vf) (Typ)：1.2V
Current - DC Forward (If) (Max)：50 mA
Vce Saturation (Max)：200mV
Operating Temperature：-30°C ~ 100°C
Mounting Type：Surface Mount
Package / Case：4-SMD, Gull Wing
Supplier Device Package：4-Mini-Flat
Grade：-
Qualification：-

Transistor, Photovoltaic Output Optoisolators datasheet and documents for PC357N7TJ00F

PC357N7TJ00F

Transistor, Photovoltaic Output Optoisolators Overview

The PC357N7TJ00F is a transistor output optocoupler from Sharp Microelectronics, designed for high-speed and low-voltage operations. It features a 4-SMD Gull Wing package with one channel. Key electrical parameters include an isolation voltage of 3750Vrms, a maximum collector-emitter voltage of 80V, and a maximum collector current of 50mA. The device operates within a temperature range of -30°C to +100°C, with typical rise and fall times of 18μs.

Transistor, Photovoltaic Output Optoisolators Feature Summary

Optimized for high-speed and low-voltage applications
Provides excellent performance for analog and digital signal transmission
Designed for high-reliability operations in harsh environments

Transistor, Photovoltaic Output Optoisolators Applications

High-speed signal transmission
Low-voltage operation circuits
Analog and digital interface isolation

Transistor, Photovoltaic Output Optoisolators Procurement Notes

Verify the exact part number suffix against official Sharp Microelectronics documentation to ensure correct pinout and electrical characteristics. Confirm that the 4-SMD Gull Wing package matches your PCB footprint requirements. Check for specific RoHS compliance status if required by your manufacturing standards. Ensure the operating temperature range meets your environmental specifications.

Transistor, Photovoltaic Output Optoisolators Selection Notes

Select this component when high-speed switching and low-voltage compatibility are critical. The 3750Vrms isolation voltage provides robust protection between input and output circuits. Consider the 18μs response time for timing-sensitive applications. Verify that the 50mA collector current capability suits your load requirements.

Transistor, Photovoltaic Output Optoisolators Part Context

This part belongs to Sharp's transistor output optocoupler family, specifically engineered for reliability in demanding conditions. It shares the core technology of the PC357NJ series but is packaged in a surface-mount Gull Wing format suitable for automated assembly processes.
