PC367N1J000F

$0.72

Description：OPTOISO 3.75KV TRANS 4-MINI-FLAT
Series：-
Mfr：Sharp Microelectronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:7dbceb112c54 Category: Transistor, Photovoltaic Output Optoisolators Brand: Sharp Microelectronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PC367N1J000F is listed in the Transistor, Photovoltaic Output Optoisolators range at ChipApex. The manufacturer field lists Sharp Microelectronics. Its product description is OPTOISO 3.75KV TRANS 4-MINI-FLAT. Review the specifications below when checking this part for your BOM.

Transistor, Photovoltaic Output Optoisolators specifications for PC367N1J000F

Description：OPTOISO 3.75KV TRANS 4-MINI-FLAT
Series：-
Mfr：Sharp Microelectronics
Package：Tape & Reel (TR),Cut Tape (CT)
Number of Channels：1
Voltage - Isolation：3750Vrms
Current Transfer Ratio (Min)：150% @ 500µA
Current Transfer Ratio (Max)：300% @ 500µA
Turn On / Turn Off Time (Typ)：-
Rise / Fall Time (Typ)：4µs, 3µs
Input Type：DC
Output Type：Transistor
Voltage - Output (Max)：80V
Current - Output / Channel：50mA
Voltage - Forward (Vf) (Typ)：1.2V
Current - DC Forward (If) (Max)：10 mA
Vce Saturation (Max)：200mV
Operating Temperature：-30°C ~ 100°C
Mounting Type：Surface Mount
Package / Case：4-SMD, Gull Wing
Supplier Device Package：4-Mini-Flat
Grade：-
Qualification：-

Transistor, Photovoltaic Output Optoisolators datasheet and documents for PC367N1J000F

PC367N1J000F

Transistor, Photovoltaic Output Optoisolators Overview

The PC367N1J000F is a single-channel transistor output optocoupler manufactured by Sharp Microelectronics. It features a 4-Mini-Flat surface-mount package with a 3750 Vrms isolation voltage. The device utilizes an NPN phototransistor output capable of handling up to 80V collector-emitter voltage and 8mA collector current. Key electrical parameters include a forward current of 50 mA, forward voltage of 1.4 V, and saturation voltage of 200 mV. The unit offers a typical rise time of 4 µs and fall time of 3 µs, with a power dissipation rating of 170 mW.

Transistor, Photovoltaic Output Optoisolators Feature Summary

High common mode rejection ratio for AC input applications
Low input current operation capability
Miniaturized 4-pin Mini-Flat surface mount packaging

Transistor, Photovoltaic Output Optoisolators Applications

AC mains detection circuits
Industrial control system signal isolation
Power supply feedback loops

Transistor, Photovoltaic Output Optoisolators Procurement Notes

Verify the specific Current Transfer Ratio (CTR) ranking upon order confirmation, as the suffix '1' indicates a specific binning category within the PC367 series. Ensure compatibility with the 4-Mini-Flat footprint during PCB layout. Confirm RoHS compliance status through the latest manufacturer documentation prior to final procurement decisions.

Transistor, Photovoltaic Output Optoisolators Selection Notes

Select this component when high-speed switching is required alongside robust insulation in a compact form factor. The low input current characteristic makes it suitable for energy-efficient designs. Compare against standard SOP-4 packages if space constraints allow, but prioritize the Mini-Flat profile for dense board layouts requiring 3750 Vrms isolation.

Transistor, Photovoltaic Output Optoisolators Part Context

This part belongs to the PC367NJ0000F series, designed specifically for high Common Mode Rejection (CMR) performance. It serves as a modern replacement for older through-hole or larger SMD optocouplers in applications demanding reliable signal transmission across isolated boundaries while minimizing physical footprint on the circuit board.
