PC724V0NIPXF

$1.22

Description：OPTOISOLATOR 5KV 1CH TRANS 6-SMD
Series：-
Mfr：Sharp Microelectronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:06c2378dcf4e Category: Transistor, Photovoltaic Output Optoisolators Brand: Sharp Microelectronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PC724V0NIPXF is listed in the Transistor, Photovoltaic Output Optoisolators range at ChipApex. The manufacturer field lists Sharp Microelectronics. Its product description is OPTOISOLATOR 5KV 1CH TRANS 6-SMD. Review the specifications below when checking this part for your BOM.

Transistor, Photovoltaic Output Optoisolators specifications for PC724V0NIPXF

Description：OPTOISOLATOR 5KV 1CH TRANS 6-SMD
Series：-
Mfr：Sharp Microelectronics
Package：Tape & Reel (TR),Cut Tape (CT)
Number of Channels：1
Voltage - Isolation：5000Vrms
Current Transfer Ratio (Min)：20% @ 100mA
Current Transfer Ratio (Max)：80% @ 100mA
Turn On / Turn Off Time (Typ)：-
Rise / Fall Time (Typ)：4µs, 3µs
Input Type：DC
Output Type：Transistor
Voltage - Output (Max)：35V
Current - Output / Channel：80mA
Voltage - Forward (Vf) (Typ)：1.4V
Current - DC Forward (If) (Max)：150 mA
Vce Saturation (Max)：200mV
Operating Temperature：-25°C ~ 100°C
Mounting Type：Surface Mount
Package / Case：6-SMD, Gull Wing
Supplier Device Package：6-SMD
Grade：-
Qualification：-

Transistor, Photovoltaic Output Optoisolators datasheet and documents for PC724V0NIPXF

PC724V0NIPXF

Transistor, Photovoltaic Output Optoisolators Overview

The PC724V0NIPXF is a photovoltaic output optoisolator manufactured by Sharp Microelectronics. It features a single channel configuration housed in a 6-SMD, Gull Wing package. The device provides an isolation voltage of 5000 Vrms and operates within a temperature range of -25°C to +100°C. The output maximum voltage is specified at 35V.

Transistor, Photovoltaic Output Optoisolators Feature Summary

Photovoltaic output architecture for zero-bias operation
High insulation voltage capability of 5000 Vrms
Surface-mount SMD-6 gull wing packaging

Transistor, Photovoltaic Output Optoisolators Applications

Battery-powered measurement equipment
Industrial control systems requiring galvanic isolation
Signal transmission in noise-sensitive environments

Transistor, Photovoltaic Output Optoisolators Procurement Notes

Verify the specific datasheet revision and RoHS compliance status directly with Sharp Microelectronics or authorized distributors before procurement. Confirm that the 6-SMD gull wing package dimensions match your PCB footprint requirements. Ensure the 35V output voltage rating is sufficient for your specific circuit load conditions.

Transistor, Photovoltaic Output Optoisolators Selection Notes

Select this component when zero-bias photovoltaic outputs are required rather than transistor-based outputs. The high isolation voltage makes it suitable for applications demanding significant electrical separation between input and output circuits. Consider the thermal operating range limits during selection.

Transistor, Photovoltaic Output Optoisolators Part Context

This part belongs to Sharp's family of photovoltaic output optocouplers. Unlike standard transistor outputs, these devices generate their own bias voltage from incident light, eliminating the need for external power on the output side. This characteristic distinguishes them from other Sharp optocoupler series like the PC817 or PC457.
