PC81716NIP0F

Transistor, Photovoltaic Output Optoisolators Overview

The PC81716NIP0F is a transistor output optocoupler manufactured by Sharp Microelectronics. It features a single channel configuration with an NPN phototransistor output. The device provides 5000 Vrms insulation voltage and operates within a temperature range of -30°C to +100°C. Key electrical parameters include a maximum collector-emitter voltage of 80 V, a maximum collector current of 2.5 mA, and a power dissipation of 170 mW. The forward voltage is 1.4 V at a forward current of 10 mA. Current transfer ratio ranges from 100% to 600%. Rise and fall times are both 18 µs.

Transistor, Photovoltaic Output Optoisolators Feature Summary

• Provides high-voltage isolation between input and output circuits
• Utilizes an NPN phototransistor for signal transmission
• Designed for surface mount installation in compact applications

Transistor, Photovoltaic Output Optoisolators Applications

• Signal isolation in industrial control systems
• Power supply feedback loops
• Microcontroller interface circuits

Transistor, Photovoltaic Output Optoisolators Procurement Notes

Verify the specific suffix and revision level against the manufacturer's latest datasheet to ensure compatibility with design requirements. Confirm RoHS compliance status and lead-free characteristics as per current regulatory standards. Check for any obsolescence notices or lifecycle changes directly from Sharp Microelectronics before finalizing procurement plans.

Transistor, Photovoltaic Output Optoisolators Selection Notes

Select this component when a single-channel transistor output optocoupler with 5000 Vrms isolation is required. Ensure the application supports the specified 170 mW power dissipation and operating temperature range. Verify that the 80 V collector-emitter voltage rating meets the circuit's maximum voltage demands.

Transistor, Photovoltaic Output Optoisolators Part Context

This part belongs to the PC817 series of transistor output optocouplers produced by Sharp Microelectronics. The series is widely used for general-purpose isolation tasks. The PC81716NIP0F specifically denotes a surface mount variant with defined electrical characteristics distinct from through-hole or other output types within the broader family.

Transistor, Photovoltaic Output Optoisolators Replacement Considerations

Publicly confirmed substitute part numbers for the PC81716NIP0F were not found in the provided source material.
