PC845XJ0000F is listed in the Transistor, Photovoltaic Output Optoisolators range at ChipApex. The manufacturer field lists Sharp Microelectronics. Its product description is OPTOISOLATOR 5KV 4CH DARL 16-DIP. Review the specifications below when checking this part for your BOM.
Transistor, Photovoltaic Output Optoisolators specifications for PC845XJ0000F
- Description：OPTOISOLATOR 5KV 4CH DARL 16-DIP
- Series：-
- Mfr：Sharp Microelectronics
- Package：Tube
- Number of Channels：4
- Voltage - Isolation：5000Vrms
- Current Transfer Ratio (Min)：600% @ 1mA
- Current Transfer Ratio (Max)：-
- Turn On / Turn Off Time (Typ)：-
- Rise / Fall Time (Typ)：60µs, 53µs
- Input Type：DC
- Output Type：Darlington
- Voltage - Output (Max)：35V
- Current - Output / Channel：80mA
- Voltage - Forward (Vf) (Typ)：1.2V
- Current - DC Forward (If) (Max)：50 mA
- Vce Saturation (Max)：1V
- Operating Temperature：-30°C ~ 100°C
- Mounting Type：Through Hole
- Package / Case：16-DIP (0.300", 7.62mm)
- Supplier Device Package：16-DIP
- Grade：-
- Qualification：-
Transistor, Photovoltaic Output Optoisolators datasheet and documents for PC845XJ0000F
Transistor, Photovoltaic Output Optoisolators Overview
The PC845XJ0000F is a high-performance, low-power chip designed for various applications. It features a maximum Vce saturation of 1V and an operating temperature range of -30°C to 100°C. The product carries a DC input type configuration.
Transistor, Photovoltaic Output Optoisolators Feature Summary
- High-performance design
- Low-power consumption
- DC input type
Transistor, Photovoltaic Output Optoisolators Applications
- IoT devices
- Wearables
Transistor, Photovoltaic Output Optoisolators Procurement Notes
Verify the exact part number PC845XJ0000F against official Sharp Microelectronics documentation to ensure compatibility. Confirm that the specified package and electrical characteristics match your system requirements before procurement.
Transistor, Photovoltaic Output Optoisolators Selection Notes
Select this component for applications requiring high performance and low power consumption. Ensure the DC input type and operating temperature range suit your specific environmental conditions.
Transistor, Photovoltaic Output Optoisolators Part Context
This component belongs to Sharp Microelectronics' portfolio of electronic chips. It is characterized by its specific electrical parameters and packaging options suitable for modern electronic designs.
