PC847X5J000F

Overview

The PC847X5J000F is a quad-channel transistor output optocoupler manufactured by Sharp Microelectronics. It features a 16-DIP package and provides 5000Vrms isolation voltage between input and output channels. The device offers a minimum current transfer ratio of 80% at a forward current of 5mA. This component is designed for applications requiring high-density signal isolation with multiple independent channels in a single package.

Feature Summary

• Quad-channel configuration for multi-signal isolation
• High isolation voltage rating of 5000Vrms
• Transistor output type for digital switching

Applications

• Industrial control systems requiring multi-channel isolation
• Data communication interfaces with galvanic separation needs
• Power supply feedback circuits

Procurement Notes

Verify the specific suffix J000F to confirm the tape and reel or tube packaging format as indicated by distributor listings. Confirm RoHS compliance status through official Sharp documentation before integration. Ensure the 16-DIP pinout matches the target PCB footprint design constraints.

Selection Notes

Select this component when four isolated channels are required within a single footprint. The 5000Vrms rating suits high-noise industrial environments. Compare the 80% CTR specification against load requirements to ensure adequate drive capability for downstream logic circuits without excessive input current.

Part Context

This part belongs to Sharp's PC847 series of quad optocouplers. It serves as a compact solution for replacing multiple discrete dual-channel units, reducing board space. The transistor output architecture is standard for general-purpose digital isolation tasks in consumer and industrial electronics.

Replacement Considerations

Check for direct pin-compatible substitutes from Sharp or other manufacturers offering 5000Vrms quad isolation. Verify that alternative parts maintain the same 16-DIP package dimensions and electrical characteristics such as CTR and isolation voltage ratings.
