Product Detailed Parameters
- Description：OPTOISOLTR 5KV 4CH TRANS 16-DIP
- Series：-
- Mfr：Sharp Microelectronics
- Package：Tube
- Number of Channels：4
- Voltage - Isolation：5000Vrms
- Current Transfer Ratio (Min)：50% @ 5mA
- Current Transfer Ratio (Max)：600% @ 5mA
- Turn On / Turn Off Time (Typ)：-
- Rise / Fall Time (Typ)：4µs, 3µs
- Input Type：DC
- Output Type：Transistor
- Voltage - Output (Max)：80V
- Current - Output / Channel：50mA
- Voltage - Forward (Vf) (Typ)：1.2V
- Current - DC Forward (If) (Max)：50 mA
- Vce Saturation (Max)：200mV
- Operating Temperature：-30°C ~ 100°C
- Mounting Type：Through Hole
- Package / Case：16-DIP (0.300", 7.62mm)
- Supplier Device Package：16-DIP
- Grade：-
- Qualification：-
Download product information
Overview
The PC847XJ0000F is a four-channel transistor output optocoupler manufactured by Sharp Microelectronics. It features an isolation voltage of 5000 Vrms and operates within a temperature range of -30°C to +100°C. The device utilizes a 16-DIP package for through-hole mounting. Key electrical parameters include a maximum collector-emitter voltage of 80V, a continuous output current of 50mA per channel, and a typical forward voltage of 1.2V at a maximum DC forward current of 50mA.
Feature Summary
- Provides galvanic isolation across four independent channels
- Utilizes phototransistor output configuration for signal transmission
- Supports high-voltage isolation up to 5000 Vrms
Applications
- Industrial control systems requiring multi-channel isolation
- Data communication interfaces with ground potential differences
- Power supply feedback circuits
Procurement Notes
Verify the specific suffix J against official Sharp documentation to confirm package type and compliance status. Ensure the procurement source provides valid RoHS certification if required. Confirm that the 16-DIP form factor matches the target PCB layout constraints before finalizing orders.
Selection Notes
Select this component when multiple isolated channels are required in a single package. The 5000 Vrms rating suits applications with significant ground potential differences. Consider the 16-DIP footprint availability during design phase. Evaluate thermal dissipation requirements given the through-hole packaging style.
Part Context
This part belongs to Sharp's transistor output optocoupler family. It shares functional similarities with other multi-channel isolators but distinguishes itself through its specific four-channel architecture and 16-pin DIP housing. It serves as a compact solution for dense circuit designs needing robust electrical separation between input and output stages.
Replacement Considerations
PC847X3NSZ9F is a documented alternative offering similar transistor output characteristics. Verify pin compatibility and isolation voltage ratings before substitution. Ensure the replacement meets the same thermal and electrical specifications for the intended application.
