PCD0302MT4R7 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Viking Tech. Its product description is FIXED IND 4.7UH 1A 170 MOHM SMD. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for PCD0302MT4R7
- Description：FIXED IND 4.7UH 1A 170 MOHM SMD
- Series：PCD
- Mfr：Viking Tech
- Package：Tape & Reel (TR)
- Type：-
- Material - Core：-
- Inductance：4.7 µH
- Tolerance：±20%
- Current Rating (Amps)：1:00 AM
- Current - Saturation (Isat)：-
- Shielding：Unshielded
- DC Resistance (DCR)：170mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.138" L x 0.118" W (3.50mm x 3.00mm)
- Height - Seated (Max)：0.094" (2.40mm)
- Features：-
Fixed Inductors datasheet and documents for PCD0302MT4R7
Fixed Inductors Overview
The Viking Tech PCD0302MT4R7 is a fixed surface-mount power inductor with an inductance of 4.7 µH and a tolerance of ±20%. It supports a rated current of 1 A and features a maximum DC resistance of 170 mΩ. The component utilizes an unshielded design suitable for standard SMD assembly processes.
Fixed Inductors Feature Summary
- Unshielded magnetic structure for compact integration
- Multilayer electrode construction for reliability
- Compatible with standard soldering processes
Fixed Inductors Applications
- General purpose power supply filtering
- DC-DC converter input/output stages
- Signal line noise suppression
Fixed Inductors Procurement Notes
Verify the manufacturer designation as Viking Tech Corp against the specific part number PCD0302MT4R7. Confirm that the electrical parameters, specifically the 4.7 µH inductance and 170 mΩ DC resistance, align with the official datasheet specifications before procurement to ensure circuit compatibility.
Fixed Inductors Selection Notes
Select this component when a non-shielded inductor is required to minimize magnetic interference with nearby sensitive components. Ensure the operating current does not exceed the 1 A rating and verify that the physical dimensions fit the designated PCB footprint for the 0302 package style.
Fixed Inductors Part Context
This component belongs to the Viking Tech PCD Series of SMD power inductors. The series offers various inductance values and current ratings within small form factors, designed for high-reliability applications in consumer electronics and industrial equipment requiring efficient power management solutions.
Fixed Inductors Replacement Considerations
Cross-reference with other 4.7 µH unshielded power inductors in the 0302 package size. Verify that substitute parts match the 1 A rated current and 170 mΩ maximum DC resistance limits to maintain equivalent circuit performance.
