PCMC063T-R22MN

$1.17

Description：FIXED IND 220NH 23A 2.5 MOHM SMD
Series：PCMC
Mfr：Susumu
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:e9a7666cb7b3 Category: Fixed Inductors Brand: Susumu

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PCMC063T-R22MN is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Susumu. Its product description is FIXED IND 220NH 23A 2.5 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PCMC063T-R22MN

Description：FIXED IND 220NH 23A 2.5 MOHM SMD
Series：PCMC
Mfr：Susumu
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：-
Inductance：220 nH
Tolerance：±20%
Current Rating (Amps)：23 A
Current - Saturation (Isat)：40A
Shielding：Unshielded
DC Resistance (DCR)：2.5mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.287" L x 0.260" W (7.30mm x 6.60mm)
Height - Seated (Max)：0.118" (3.00mm)
Features：-

Fixed Inductors datasheet and documents for PCMC063T-R22MN

PCMC063T-R22MN

Fixed Inductors Overview

The Susumu PCMC063T-R22MN is a surface-mount power inductor with an inductance of 0.22 µH and a tolerance of ±20%. It features a maximum DC resistance of 2.5 mΩ, a rated current of 23 A, and a saturation current of 13.5 A. The component measures 7.30 mm x 6.60 mm x 3.00 mm and operates at a test frequency of 100 kHz.

Fixed Inductors Feature Summary

High current handling capability for power applications
Low DC resistance to minimize power loss
Non-shielded design for general-purpose use

Fixed Inductors Applications

Power supply circuits
DC-DC converters
General-purpose electronic systems

Fixed Inductors Procurement Notes

Verify the part status as obsolete or discontinued before procurement. Confirm availability through authorized distributors or alternative sources. Ensure the replacement component matches the required electrical specifications and physical dimensions for proper integration into the circuit design.

Fixed Inductors Selection Notes

Select this component for applications requiring high current ratings and low impedance. Consider the non-shielded nature when designing for electromagnetic interference sensitivity. Verify that the saturation current meets the peak load requirements of the specific power circuit application.

Fixed Inductors Part Context

This component belongs to the Susumu PCMC series of fixed power inductors. It is designed for surface-mount technology (SMD) assembly. The series offers various inductance values tailored for different power management needs within compact form factors suitable for modern electronic devices.
