PCMC133E-R68MF

$1.48

Description：FIXED IND 680NH 28A 2.5 MOHM SMD
Series：PCMC
Mfr：Susumu
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:4c68048e97a3 Category: Fixed Inductors Brand: Susumu

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PCMC133E-R68MF is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Susumu. Its product description is FIXED IND 680NH 28A 2.5 MOHM SMD. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for PCMC133E-R68MF

Description：FIXED IND 680NH 28A 2.5 MOHM SMD
Series：PCMC
Mfr：Susumu
Package：Tape & Reel (TR),Cut Tape (CT)
Type：-
Material - Core：-
Inductance：680 nH
Tolerance：±20%
Current Rating (Amps)：28 A
Current - Saturation (Isat)：49A
Shielding：Unshielded
DC Resistance (DCR)：2.5mOhm Max
Q @ Freq：-
Frequency - Self Resonant：-
Ratings：-
Operating Temperature：-
Inductance Frequency - Test：100 kHz
Mounting Type：Surface Mount
Package / Case：Nonstandard
Supplier Device Package：-
Size / Dimension：0.530" L x 0.496" W (13.45mm x 12.60mm)
Height - Seated (Max)：0.130" (3.30mm)
Features：-

Fixed Inductors datasheet and documents for PCMC133E-R68MF

PCMC133E-R68MF

Fixed Inductors Overview

The PCMC133E-R68MF is a fixed power inductor from the Susumu PCMC series, designed for surface mount applications. It features an inductance of 0.68 µH with a tolerance of ±20%. The component has a maximum DC resistance of 2.70 mOhm and a current rating of 29.0 A, with saturation current reaching 51.0 A. Its physical dimensions are 13.45 mm in length, 12.60 mm in width, and a seated height of 2.63 mm. The device is unshielded and packaged in tape and reel quantities of 500 units.

Fixed Inductors Feature Summary

High current handling capability with specified saturation limits
Low DC resistance for efficient power transmission
Surface mount construction for automated assembly

Fixed Inductors Applications

Power supply input filtering
DC-DC converter output chokes
High-current signal path impedance control

Fixed Inductors Procurement Notes

Verify component authenticity through authorized distributors. Confirm RoHS compliance status as per latest manufacturer documentation. Check for obsolescence notices since this specific model may be discontinued; validate availability of direct replacements if production continuity is required.

Fixed Inductors Selection Notes

Select based on required inductance value and current ratings. Ensure footprint compatibility with PCB design constraints. Consider thermal management requirements given the high current capacity. Verify that the unshielded nature does not interfere with nearby sensitive components.

Fixed Inductors Part Context

This component belongs to the Susumu PCMC series of power chokes. It is part of a family of fixed inductors designed for robust performance in power electronics. The series offers various inductance values and current ratings to suit different power delivery needs.
