PCSV80-470M-RC is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Allied Components International. Its product description is 47UH 20% SHIELDED PWR INDUCTOR. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for PCSV80-470M-RC
- Description：47UH 20% SHIELDED PWR INDUCTOR
- Series：-
- Mfr：Allied Components International
- Package：Tape & Reel (TR)
- Type：Wirewound
- Material - Core：-
- Inductance：47 µH
- Tolerance：±20%
- Current Rating (Amps)：1.75 A
- Current - Saturation (Isat)：1.9A
- Shielding：Shielded
- DC Resistance (DCR)：160mOhm
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-55°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：3131 (8080 Metric)
- Supplier Device Package：3131
- Size / Dimension：0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max)：0.165" (4.20mm)
- Features：-
Fixed Inductors datasheet and documents for PCSV80-470M-RC
Fixed Inductors Overview
PCSV80-470M-RC is a shielded power inductor manufactured by Allied Components International. It features an inductance of 47 µH with a tolerance of ±20%. The component utilizes a surface-mount package design suitable for automated assembly processes. As a shielded type, it minimizes electromagnetic interference coupling to adjacent circuitry. The device is constructed to meet RoHS compliance standards for environmental safety.
Fixed Inductors Feature Summary
- Shielded magnetic structure reduces electromagnetic interference
- Surface-mount technology compatible packaging
- RoHS compliant construction
Fixed Inductors Applications
- DC-DC converter circuits
- Power supply filtering stages
- Signal processing power rails
Fixed Inductors Procurement Notes
Verify the exact part number against official Allied Components International documentation before procurement. Ensure the specific suffix matches project requirements. Confirm RoHS status through current datasheets as specifications may update. Cross-reference manufacturer codes to avoid counterfeit components during sourcing.
Fixed Inductors Selection Notes
Select this component based on required 47 µH inductance and ±20% tolerance specifications. Evaluate physical footprint compatibility with PCB layout constraints. Consider shielding requirements for sensitive signal environments. Verify thermal performance limits against expected operating currents.
Fixed Inductors Part Context
This part belongs to the PCSV80 series of shielded power inductors from Allied Components International. The series offers various inductance values within a standardized surface-mount form factor. These components are designed for general-purpose power management applications requiring compact magnetic solutions.
Fixed Inductors Replacement Considerations
Consult official substitution guides for equivalent shielded power inductors with matching 47 µH inductance and similar current ratings. Verify pinout and dimensional compatibility before replacing.
