PD1608MT6R8

Fixed Inductors Overview

The PD1608MT6R8 is a general purpose surface mount power inductor manufactured by Viking Tech Corp. It features a ferrite core and a 2618 package footprint. The nominal inductance is 6.8 µH with a tolerance of ±20%. The component has a maximum DC resistance of 0.13 ohms and a rated current of 45 A. It operates within a temperature range defined by standard environmental specifications.

Fixed Inductors Feature Summary

• Utilizes a shielded ferrite core design for electromagnetic interference suppression
• Constructed for surface mount technology (SMD) integration
• Designed to withstand high-temperature storage conditions without case deformation

Fixed Inductors Applications

• General purpose power supply circuits
• DC-DC converter filtering
• Industrial electronic equipment

Fixed Inductors Procurement Notes

Verify the manufacturer designation carefully, as similar part numbers exist from other suppliers such as SEI. Confirm that the specific voltage rating and current handling capabilities align with the target circuit requirements before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when a 6.8 µH inductance value is required in a 2618 footprint. Ensure the application current does not exceed the specified 45 A limit. Consider the thermal management requirements associated with the low DC resistance characteristic for efficient power delivery.

Fixed Inductors Part Context

This component belongs to the PD series of SMD power inductors produced by Viking Tech Corporation. The company specializes in passive components, including resistors and integrated passive devices, serving automotive and industrial markets with certified quality systems.

Fixed Inductors Replacement Considerations

Public documentation lists PD1608MT1R0 and PD1608MT100 as related parts within the same series. Verify electrical compatibility for direct substitution based on specific inductance needs.
