PE-1210AGC510STS

$0.69

Description：CMC 200MA 2LN 2.6 KOHM SMD
Series：1210 AGC
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:12553b618dcf Category: Common Mode Chokes Brand: Pulse Electronics

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

PE-1210AGC510STS is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists Pulse Electronics. Its product description is CMC 200MA 2LN 2.6 KOHM SMD. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for PE-1210AGC510STS

Description：CMC 200MA 2LN 2.6 KOHM SMD
Series：1210 AGC
Mfr：Pulse Electronics
Package：Tape & Reel (TR),Cut Tape (CT)
Filter Type：Signal Line
Number of Lines：2
Current Rating (Max)：200mA
DC Resistance (DCR) (Max)：1.5Ohm
Voltage Rating - DC：80V
Voltage Rating - AC：-
Operating Temperature：-40°C ~ 125°C
Ratings：AEC-Q200
Approval Agency：-
Features：-
Mounting Type：Surface Mount
Size / Dimension：0.126" L x 0.098" W (3.20mm x 2.50mm)
Height (Max)：0.102" (2.60mm)
Package / Case：Horizontal, 4 PC Pad
Inductance @ Frequency：-
Impedance @ Frequency：2.6 kOhms @ 10 MHz

Common Mode Chokes datasheet and documents for PE-1210AGC510STS

PE-1210AGC510STS

Common Mode Chokes Overview

The PE-1210AGC510STS is a two-line surface mount common mode choke manufactured by Pulse Electronics. It operates within an ambient temperature range of -40°C to +125°C and holds AEC-Q200 automotive qualification. The component provides a nominal impedance of 2600 Ohms at 10 MHz, supports a maximum current of 0.2 Amperes, and features a DC resistance of 1.5 Ohms.

Common Mode Chokes Feature Summary

AEC-Q200 qualified for automotive reliability standards
Dual-line configuration for differential signal protection
Surface mount design for automated assembly

Common Mode Chokes Applications

Automotive CAN bus networks
High-speed data line filtering
Electromagnetic interference suppression in vehicles

Common Mode Chokes Procurement Notes

Verify the specific suffix STS against official datasheets to confirm package and tape specifications. Confirm AEC-Q200 compliance requirements with the manufacturer before finalizing procurement orders for automotive applications.

Common Mode Chokes Selection Notes

Select this component when dual-channel EMI filtering is required for automotive data lines. Ensure the operating environment stays within the specified -40°C to +125°C range and that the 0.2A current rating meets circuit demands.

Common Mode Chokes Part Context

This part belongs to the PulseChip family of automotive chokes designed for robust electromagnetic compatibility. It serves as a specialized filter for protecting sensitive communication interfaces against noise in demanding vehicular environments.

Common Mode Chokes Replacement Considerations

Consult official substitution lists for equivalent impedance and current ratings. Verify pinout compatibility and thermal characteristics before replacing existing designs.
