PE-W28AT001-30

Overview

The PE-W28AT001-30 is a fixed RF attenuator module manufactured by Pasternack. It provides an attenuation value of 30 dB within the frequency range of 26.5 GHz to 40 GHz. The device is rated for a power handling capacity of 5 Watts. This component is designed for high-frequency signal control applications requiring precise attenuation in millimeter-wave bands.

Feature Summary

• Provides fixed 30 dB attenuation
• Operates from 26.5 GHz to 40 GHz
• Rated for 5W power handling

Applications

• Millimeter-wave test and measurement systems
• High-frequency signal conditioning
• RF circuit power level adjustment

Procurement Notes

Verify the specific datasheet for detailed electrical specifications and mechanical dimensions before integration. Confirm that the operating environment remains within the specified 26.5 GHz to 40 GHz frequency range and does not exceed the 5 Watt power rating. Ensure compatibility with the required connector interface type for proper system installation.

Selection Notes

Select this model when a fixed 30 dB reduction is required at frequencies up to 40 GHz. Consider the 5 Watt power limit for thermal management. Compare against variable attenuators if adjustable attenuation is needed, or lower loss models if minimal insertion loss is critical for the specific application path.

Part Context

This part belongs to the Pasternack RF attenuator product line. It serves as a passive component for reducing signal amplitude in microwave and millimeter-wave circuits. The module format suggests it is designed for easy integration into larger RF assemblies or test setups requiring stable attenuation performance.

Replacement Considerations

No public substitute part numbers are confirmed in the provided documentation. Verify exact electrical parameters and physical dimensions when evaluating alternative components from other manufacturers to ensure functional equivalence.
