PE1632

Overview

The Pasternack PE1632 is a broadband bias tee designed for RF applications, operating within a frequency range of 50 kHz to 18 GHz. It utilizes SMA connectors for interface compatibility and is rated for a maximum DC current of 750 mA and a voltage of 25 Volts on the DC pin. The component functions as a general-purpose RF device, enabling the injection or extraction of DC signals onto RF lines without disrupting signal integrity across its specified bandwidth.

Feature Summary

• Provides broadband performance from 50 kHz to 18 GHz
• Integrates SMA connector interfaces for standard RF connectivity
• Supports DC bias currents up to 750 mA at 25 Volts

Applications

• RF circuit biasing in test and measurement equipment
• Integration into wireless communication systems requiring DC/RF separation
• General purpose RF signal conditioning modules

Procurement Notes

Verify that the specific revision matches the required frequency and current ratings. Confirm SMA connector gender and cable assembly specifications if applicable. Ensure environmental conditions align with operational requirements for high-frequency stability.

Selection Notes

Select this component when a wideband solution between 50 kHz and 18 GHz is required. Consider the 750 mA current limit for power handling needs. Verify impedance matching and connector type compatibility with existing system infrastructure before integration.

Part Context

The PE1632 belongs to Pasternack's portfolio of RF and microwave components, specifically within the bias tee category. It serves as a passive interconnect device facilitating simultaneous DC and RF signal transmission over a single line, essential for powering active RF components while maintaining signal purity.

Replacement Considerations

No direct public substitute part numbers are confirmed for this specific model.
