Product Detailed Parameters
- Description：2 GHz Phase Locked Oscillator, 1
- Series：-
- Mfr：Pasternack
- Package：Retail Package
- Function：RF Oscillator
- Frequency：2GHz
- RF Type：General Purpose
- Secondary Attributes：SMA Connectors
- Mounting Type：Chassis Mount
- Package / Case：Module, SMA Connectors
- Supplier Device Package：Module
- Grade：-
- Qualification：-
Download product information
Overview
The PE19XC7002 is a phase-locked loop oscillator manufactured by Pasternack. It operates at a frequency of 2 GHz and utilizes an SMA connector interface. The device accepts a 10 MHz external reference signal to maintain phase lock. It achieves a phase noise performance of -100 dBc/Hz. This component is designed for RF applications requiring stable frequency generation.
Feature Summary
- Integrates a phase-locked loop architecture for precise frequency control
- Accepts a 10 MHz external reference input for synchronization
- Generates a stable 2 GHz output signal with specified phase noise characteristics
Applications
- RF test and measurement equipment
- Wireless communication systems
- Signal generation modules
Procurement Notes
Verify the specific datasheet version for the PE19XC7002 to confirm exact electrical tolerances and pinout configurations before integration. Ensure that the external reference source meets the required 10 MHz specification to guarantee proper phase-locking operation. Check for any RoHS compliance documentation if environmental regulations apply to the assembly process.
Selection Notes
Select this component when a fixed 2 GHz output is required with low phase noise. The requirement for a 10 MHz external reference must be accommodated in the system design. Compare against other oscillators if different frequencies or reference inputs are needed. Verify that the SMA connector type matches the existing PCB layout or cable assembly requirements.
Part Context
This part belongs to Pasternack's range of RF semiconductors and devices, specifically within their specialist oscillator category. It is distinct from their passive components like attenuators and adapters. The product line focuses on providing reliable active RF solutions for professional engineering applications.
Replacement Considerations
No direct substitute part numbers are publicly confirmed for this specific model. Engineers should evaluate alternative 2 GHz phase-locked oscillators with similar phase noise specifications and compatible reference inputs if replacement is necessary.
