PE1V12001

$47.17

Description：Surface Mount (SMT) Voltage Cont
Series：-
Mfr：Pasternack
Package：Retail Package

SKU:1f092a780806 Category: VCOs (Voltage Controlled Oscillators) Brand: Pasternack

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：Surface Mount (SMT) Voltage Cont
Series：-
Mfr：Pasternack
Package：Retail Package
Frequency Range：195 ~ 240MHz
Frequency - Center：217.5MHz
Voltage - Supply：5V
Tuning Voltage (VDC)：0 V ~ 15 V
2nd Harmonic, Typ (dBc)：-15
Icc Max：22mA
Pushing (MHz/V)：0.2
Power (dBm)：8.5 ±0.5
Phase Noise Typ (dBc/Hz)：-125
Operating Temperature：-40°C ~ 85°C
Package / Case：16-SMD, No Lead
Size / Dimension：0.500" L x 0.500" W (12.70mm x 12.70mm)
Height：0.162" (4.11mm)

Download product information

PE1V12001

Overview

The PE1V12001 is a Surface Mount (SMT) Voltage Controlled Oscillator (VCO) manufactured by Pasternack. It operates within a frequency range of 195 MHz to 240 MHz. The device features a phase noise performance of -125 dBc/Hz. It utilizes a 0.5 inch package design suitable for high-reliability applications requiring robust surface mount integration.

Feature Summary

Surface Mount (SMT) Voltage Controlled Oscillator (VCO) architecture
Frequency coverage from 195 MHz to 240 MHz
Phase noise specification of -125 dBc/Hz
Utilizes a 0.5 inch package form factor

Applications

RF communication systems
Microwave signal generation
General-purpose RF applications

Procurement Notes

Verify the specific datasheet revision and manufacturer documentation when sourcing this component. Ensure that the ordering suffixes match the required electrical specifications, as variations may exist within the product line. Confirm compatibility with the intended surface mount assembly process and environmental requirements before finalizing procurement decisions.

Selection Notes

Select the PE1V12001 for applications requiring a VCO in the 195 MHz to 240 MHz band with specified phase noise characteristics. Consider the 0.5 inch SMT package dimensions for PCB layout constraints. Evaluate if the standard voltage control parameters meet the system tuning requirements compared to other models in the series.

Part Context

This component belongs to Pasternack's portfolio of RF and microwave products, which includes cable assemblies, connectors, and active components. The PE1V12001 represents the company's offering in surface mount oscillators designed for reliable signal transmission in various communication and electronic systems.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Users should consult official Pasternack resources or authorized distributors for cross-reference information regarding equivalent or compatible voltage controlled oscillators.
