Product Detailed Parameters
- Description：Voltage Controlled Oscillator (V
- Series：-
- Mfr：Pasternack
- Package：Retail Package
- Frequency Range：40 ~ 80MHz
- Frequency - Center：60MHz
- Voltage - Supply：15V
- Tuning Voltage (VDC)：0.5 V ~ 20 V
- 2nd Harmonic, Typ (dBc)：-14
- Icc Max：20mA
- Pushing (MHz/V)：0.05
- Power (dBm)：12 ±2
- Phase Noise Typ (dBc/Hz)：-117
- Operating Temperature：-40°C ~ 85°C
- Package / Case：Module, SMA Connectors
- Size / Dimension：0.949" L x 0.949" W (24.10mm x 24.10mm)
- Height：0.285" (7.24mm)
Download product information
Overview
The PE1V31003 is a Voltage Controlled Oscillator (VCO) manufactured by Pasternack. It operates within a frequency range of 40 MHz to 80 MHz, with a center frequency of 60 MHz. The device exhibits a phase noise specification of -117 dBc/Hz and utilizes SMA connectors for signal interface. It requires a supply voltage of 15 V for operation. This component is classified as obsolete in the manufacturer's current product lineup.
Feature Summary
- Voltage-controlled oscillation capability across a defined microwave frequency band
- Integrated SMA connector interface for RF output transmission
- Optimized phase noise performance for signal purity
Applications
- Frequency synthesis systems requiring stable local oscillator signals
- Communication equipment utilizing 40-80 MHz operational bands
- Test and measurement instrumentation for signal generation
Procurement Notes
Verify availability status carefully as this part is listed as obsolete. Confirm compatibility with existing system requirements before procurement attempts. Check for authorized distributors or surplus stock sources. Ensure replacement strategies are evaluated due to end-of-life status. Validate technical specifications against current design needs prior to acquisition.
Selection Notes
Consider the obsolete status when selecting this component for new designs. Evaluate alternative modern VCOs with similar frequency ranges if long-term supply stability is required. Verify that the 15 V supply requirement aligns with available power rails. Assess whether the SMA interface meets mechanical constraints of the target application.
Part Context
This component belongs to Pasternack's Voltage Controlled Oscillator series. It serves as a specialized RF signal source for applications demanding precise frequency control within the 40-80 MHz range. The device represents a legacy solution in the company's portfolio, now marked as discontinued.
Replacement Considerations
No public confirmed substitute part numbers are available from Pasternack for this obsolete model. Engineers should consult general industry equivalents or contact the manufacturer directly for potential obsolescence management options.
